Victory ROSE - SPA Operation Guide; Bathtub Connections Diagram and Filling

1Suctionofthefilterpump A connectedwiththestillingbasin,
3Suctionofthehydro-massagepumpBconnectedwithsuctionnozzles,
4Hydro-massagepumppistonconnectedwiththetabulationofthehydro-massage,
6filter-cleaningassist,
7connectionviaanelectrovalvetothewatersupplysystem
8directconnectiontothewatersupplysystem,
9drainingvalves
E
B
C
C
D
S
K
7
J
I
8
B B
9
9
9
9
H
G
1
6
3
3
3
4
4
4
A
II.Operation
1.Bathtubconnectionsdiagram
A Filtrationpump
BHydromassagepump
C Airblower-airmassage
D Airblower- TurboCharging
EElectronics
F Temperaturesensor
GFlowsensor
H6kWheater
I-Electricvalve
J-Prefilter
K-Stillingbasin
- Massagenozzlessection
Zdrainingvalves
Remark:Incaseofabreakdownallthevalvesshallbeclosed.
Donotregulatethevalvemarkedas[S]service.
Thewhirlpoolbathrequiresapermanentconnectiontothewatersupply. Thebathhousingisequipped
withaconnectionwhichoughttobeconnectedtothewatersupply.
