6 | P a g e
connect it to the FX loop return or ‘power amp in’ of your amp, but be aware that your
own amp’s preamp is out of the game if you do this.
REMOTE SWITCH (on side, not shown)
Accepts a 6.3mm / ¼ inch TRS jack for remote switching. The tip connection switches the
pedal on and off (Bypass) and the ring switches between channels 1 & 2. You can use any
TRS latching footswitch for this, or the control jacks on your pedalboard switcher etc. The
official Victory Remote Switch is available from out online store: www.victorystore.co.uk
Power, (12Vdc IN)
Yes, 12V DC and 800mA. 800mA is a lot for a pedal and not many power supplies will put
that out, so please don’t try daisy chaining this off your standard wall-wart. It’s why
there’s one supplied with the pedal: four valves running at decent voltages. The PSU is
capable of delivering over 2Amps so has more than enough headroom for your Preamp
Pedal.
A proper all-valve preamp needs plenty of juice.
Control Panel
