Vident iBT200 - Structure of Meter; Operation Instruction

4. Structure of Meter
iBT200 Battery Tester
BACK ENTER
< ▲> increase the value / page up
<
▼
> decrease the value / page down
<
BACK
> cancel / return
<
ENTER
> confirm / test
<
>
restart unit / return under any status
<
> battery good condition light
<
> battery warning condition light
<
> battery bad condition light
< Red Clamp > positive connection
<Black Clamp> negative connection
5. Operation Instruction
The tester is powered by the vehicle battery. Please connect the RED
clamp to the positive terminal, and connect the Black clamp to the
negative terminal. Connect the RED clamp prior to Black one is suggested.
The tester is ready to use along with the screen displays as below.
Please check and reconnect two clamps fully and firmly connected to the
terminals in case the screen displays as below.
3
