2.2 DIAGRAMMI PER MODELLI
Di seguito sono riportati i diagrammi con valori inerenti ai vari modelli.
2.2.1 STATICA UTILE ALLE VELOCITÀ L, M, H DEL
VENTILATORE (fig. 3)
2.2 DIAGRAMS FOR MODELS
Below, some diagrams for models
2.2.1 STATIC PRESSURE AT FAN SPEED L,M,H, (fig. 3)
fig. 3
0
2
4
6
8
10
12
14
0 50 100 150 200 250 300 350
Perditadicarico[KPa]
Pressuredrop[KPa]
Portata[l/h]
Waterflowrate[l/h]
PerditedicaricocircuitoidraulicoDHS/DHSC/DHP220
HydrauliccircuitpressuredropDHS/DHSC/DHP220
0
10
20
30
0 50 100 150 200 250 300 350 400 450 500
Perditadicarico[KPa]
Pressuredrop[KPa]
Portata[l/h]
Waterflowrate[l/h]
PerditedicaricocircuitoidraulicoDHS/DHSC360
HydrauliccircuitpressuredropDHS/DHSC360
8
