35
1.
SW17
2.
Fig. 26
Only type AWBT(-M)-AC/AWBT(-M)-E-AC: Connecting the cooling circuit
Contact humidistat
For area cooling systems (e.g. underfloor heating cir-
cuit, chilled ceiling), a contact humidistat (accessories)
is required.
Installation sequence
Aligning the indoor unit
6199592
Installation
