Deactivating the service menu
The service menu remains active until it is disabled
with "Terminate service?", or if no key is pressed for
30 min.
Setting parameters using "System scheme 7000"
as an example
To set a parameter, first select the parameter group
and then the parameter.
Service menu:
1. Press and hold OK + å simultaneously for
approx. 4 s.
2. Select "Coding level 1".
3. Select parameter group: "System definition"
4. Select parameter: "System scheme 7000"
5. Set a system scheme: e.g. "6"
Alternatively, if the service menu was already active:
Extended menu:
1. å
2. "Service"
3. Select "Coding level 1".
4. Select parameter group: "System definition"
5. Select parameter: "System scheme 7000"
6. Set a system scheme: e.g. "6"
Required heat pump parameters
"Output compressor stage 5030"
During commissioning, the heating output of the heat
pump must be set subject to type.
Types 111.B04 111.B06 111.B08 111.A12 111.A14 111.A16
"Output compressor stage 5030" 4 kW 6 kW 8 kW 12 kW 14 kW 16 kW
Required parameters for components connected on site
Parameters may need to be set subject to the appli-
ance type, the selected system scheme and the acces-
sories used.
Overview of required parameters: See the following
chapter.
Detailed explanations of parameters
"Vitotronic 200" service instructions
System scheme
Notes regarding the installation kit with mixer
("Type of assembly kit 7044" set to "1")
The following system components are not monitored,
even if this is shown in the system scheme:
■
Heating water buffer cylinder in the secondary circuit
flow
■
Heating circuit M3/HC3 (room heating and room
cooling)
■
Separate cooling circuit
Commissioning, inspection, maintenance
Commissioning the system (cont.)
