Equipment required
ID: 4605094_1304_05
Pos. Designation Part no.
1
Heat pump Vitocal 300-A See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
with electrical connecting cables See Viessmann pricelist
3
Outside temperature sensor ATS Standard delivery pos. 1
4
Instantaneous heating water heater, 3, 6, or 9 kW For AWCI: Z006 463
For AWO: Z007 884
5
– For type AWCI: 3-way diverter valve for "Central heating/DHW heating"
or
Standard delivery pos. 1
– For type AWO: Circulation pump for cylinder heating UPSB See Viessmann pricelist
6
Secondary pump For AWCI: Standard delivery
For AWO: see pricelist
7
Flow temperature sensor (integral for type AWCI) VTS Standard delivery pos. 1
qW
Safety equipment block with safety assembly For AWCI: Standard delivery
For AWO: 7143 779
qE
Expansion vessel See Vitoset pricelist
qT
Flow switch Standard delivery pos. 1
DHW heating
eP
Vitocell 100-V DHW cylinder, type CVW, 390 litres Z002 885
eQ
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP See Vitoset pricelist
DHW heating with solar backup
eW
Cylinder temperature sensor in the solar return STS Standard delivery pos. 47
eE
High limit safety cut-out STB for stopping the circulation pump for cylinder heating on site
eO
Solar heat exchanger set for installation on the Vitocell 100-V, type CVW 7186 663
rQ
High limit safety cut-out STB Z001 889
rW Solar-Divicon, type PS10 with integral Vitosolic 100, type SD1 rU
or
Solar-Divicon, type PS20 without control unit with separate Vitosolic 100, type SD1
rU
Z012 018
Z012 027
rE
Solar circuit pump R1 Standard delivery pos. 42
rR
Collector temperature sensor KOL Standard delivery pos. 47
rT
Solar collector See Viessmann pricelist
rU
Vitosolic 100, type SD1 Z007 387
Heating water buffer cylinder
zP
Heating water buffer cylinder See Viessmann pricelist
zQ
Buffer temperature sensor PTS 7170 965
zW
Flow temperature sensor system VTS
– As immersion temperature sensor
or
7170 965
– As contact temperature sensor 7426 133
Heating circuit with mixer M2
uP
Underfloor heating circuit M2 with mixer controlled by the heat pump control unit See Vitoset pricelist
uE
Flow temperature sensor M2 VTS 7183 288
uR
Temperature limiter to restrict the maximum temperature of underfloor heating systems
– As immersion thermostat
or
7151 728
– As contact thermostat 7151 729
uZ
Heating circuit pump M2 on site
uU
3-way mixer, heating circuit M2 See Viessmann pricelist
uU
Mixer motor 7450 657
Heating circuit without mixer A1
oP
Radiator heating circuit A1 See Vitoset pricelist
oZ
Heating circuit pump A1 on site
Heating circuit with mixer M3
q-P
Radiator heating circuit M3 controlled via the KM BUS of the heat pump control unit See Vitoset pricelist
q-E
Flow temperature sensor heating circuit M3 VTS Standard delivery pos. 105
q-T
Mixer extension kit 7301 063
q-Z
Heating circuit pump M3 See Vitoset pricelist
q-U
3-way mixer, heating circuit M3 See Viessmann pricelist
Mixer motor for 3-way mixer Standard delivery pos. 105
Vitocal 300-A/350-A
(cont.)
System examples
