Equipment required
ID: 4605093_1304_05
Pos. Designation Part no.
1
Heat pump Vitocal 300-A See Viessmann pricelist
2
Heat pump control unit Vitotronic, type WO1B Standard delivery pos. 1
with electrical connecting cables See Viessmann pricelist
3
Outside temperature sensor ATS Standard delivery pos. 1
4
Instantaneous heating water heater See Viessmann pricelist
5
– For type AWCI: 3-way diverter valve for "Central heating/DHW heating"
or
Standard delivery pos. 1
– For type AWO: Circulation pump for cylinder heating UPSB See Viessmann pricelist
6
Secondary pump For AWCI: Standard delivery
For AWO: see pricelist
7
Flow temperature sensor (integral for type AWCI) VTS Standard delivery pos. 1
qW
Safety equipment block with safety assembly 7143 779
qE
Expansion vessel See Vitoset pricelist
qT
Flow switch Standard delivery pos. 1
DHW heating
eP
Vitocell 100-V DHW cylinder, type CVW, 390 litres Z002 885
eQ
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP See Vitoset pricelist
DHW heating with a solar thermal system
eW
Cylinder temperature sensor in the solar return STS Standard delivery pos. 47
eE
High limit safety cut-out STB for stopping the circulation pump for cylinder heating on site
eO
Solar heat exchanger set for installation on the Vitocell 100-V, type CVW 7186 663
rQ
High limit safety cut-out STB (if required) Z001 889
rW Solar-Divicon, type PS10 with integral Vitosolic 100, type SD1 rU
or
Solar-Divicon, type PS20 without control unit with separate Vitosolic 100, type SD1
rU
Z012 018
Z012 027
rE
Solar circuit pump R1 Standard delivery pos. 42
rR
Collector temperature sensor KOL Standard delivery pos. 47
rT
Solar collector See Viessmann pricelist
rU
Vitosolic 100, type SD1 Z007 387
Heating water buffer cylinder
zP
Heating water buffer cylinder See Viessmann pricelist
zQ
Buffer temperature sensor PTS 7170 965
zW
Flow temperature sensor system VTS
– As immersion temperature sensor
or
7170 965
– As contact temperature sensor 7426 133
Heating/cooling circuit with mixer M2
uP
Underfloor heating circuit/cooling circuit M2 with mixer controlled by the heat pump control unit See Vitoset pricelist
uQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
-Wireless base station Z011 413
-Vitotrol 200 RF wireless remote control Z011 219
-Wireless repeater 7456 538
uE
Flow temperature sensor heating circuit M2 VTS 7183 288
uR
Temperature limiter to restrict the maximum temperature of underfloor heating systems
– Version with immersion temperature sensor
or
7151 728
– Version with contact temperature sensor 7151 729
uZ
Heating circuit pump M2 See Vitoset pricelist
uU
3-way mixer, heating circuit M2 See Viessmann pricelist
Mixer motor for 3-way mixer 7450 657
qCP
Connection module with single room control, heating/cooling with pump logic 7247 845
qCQ
Room thermostat (installation on finished walls), heating/cooling RTR-E 6726 7247 853
qCW
Thermal actuator TS 5.11/230 (N/C, cores can be interchanged)
or
Thermal actuator TS+ 5.11/230 (N/C, cores can be interchanged)
7373 722
7419 860
Active cooling function AC
qI
Frost stat 7179 164
iE
Contact humidistat 230 V 7452 646
iU
3-way diverter valve "Heating/cooling" in the return 7814 924
iI
3-way diverter valve "Heating/cooling" in the flow 7814 924
Vitocal 300-A/350-A
(cont.)
System examples
VIESMANN
217
5822 472 GB
7
