Equipment required
ID: 4605405_1304_03
Pos. Designation Part no.
1
2
Vitocal 200-G heat pump, type BWC
Heat pump control unit Vitotronic 200, type WO1B
As per Viessmann pricelist
Standard delivery pos. 1
3
Outside temperature sensor ATS Standard delivery pos. 1
4
Instantaneous heating water heater (optional) Z009 562
6
Secondary pump Standard delivery pos. 1
7
Circulation pump for cylinder heating UPSB Standard delivery pos. 1
qW
Safety equipment block with safety assembly Standard delivery pos. 1
qE
Expansion vessel for the heating circuit See Vitoset pricelist
qT
Primary pump Standard delivery pos. 1
wP
Brine accessory pack As per Viessmann pricelist
wQ
Pressure switch, brine circuit 9532 663
wW
Brine distributor for geothermal probes/geothermal collectors As per Viessmann pricelist
wU
Geothermal probe/geothermal collector on site
DHW heating
eP
DHW cylinder Vitocell 100-V, type CVW Z002 885
eW
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP (optional) See Vitoset pricelist
oP
Heating circuit without mixer (underfloor heating circuit)
oW
Overflow valve on site
oE
Temperature limiter to restrict the maximum temperature of underfloor heating systems (option-
al)
7151 728 or
7151 729
Accessories (optional)
oQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
– Wireless base station
– Vitotrol 200 RF wireless remote control
– Wireless outside temperature sensor
– Wireless repeater
Z011 413
Z011 219
7455 213
7456 538
oI
LON communication module 7172 173
qXP
Vitocom 100 type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100 type LAN 1 with communication module Z011 224
qXW
Vitocom 200 type LAN 2 with communication module Z011 390
qXE
Vitocom 200 type GP 3 with communication module with SIM card Z011 392
Vitocal 200-G
(cont.)
System examples
VIESMANN
55
5822 472 GB
3
