Equipment required
ID: 4605363_1304_03
Pos. Designation Part no.
1
Vitocal 200-G heat pump, type BWC See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
3
Outside temperature sensor ATS Standard delivery pos. 2
4
Instantaneous heating water heater Z009 562
6
Secondary pump Standard delivery pos. 1
7
Circulation pump for cylinder heating UPSB Standard delivery pos. 1
qW
Safety equipment block with safety assembly Standard delivery pos. 1
qE
Expansion vessel, heating circuit See Vitoset pricelist
qR
High limit safety cut-out STB 70 °C (for stopping the circulation pump for cylinder heating) on site
qT
Primary pump Standard delivery pos. 1
wP
Brine accessory pack See Viessmann pricelist
wQ
Pressure switch, brine circuit 9532 663
wW
Brine distributor for geothermal probes/geothermal collectors See Viessmann pricelist
wU
Geothermal probe/geothermal collector on site
DHW heating
eP
DHW cylinder Vitocell 100-V, type CVW Z002 885
eW
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP See Vitoset pricelist
DHW heating with a solar thermal system
eP
DHW cylinder Vitocell 100-V, type CVW Z002 885
eQ
Cylinder temperature sensor in the solar return SOL Standard delivery pos. 47
eW
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP See Vitoset pricelist
eO
Solar heat exchanger set for installation on the Vitocell 100-V, type CVW 7186 663
rQ
High limit safety cut-out STB (if required) Z001 889
rW Solar-Divicon, type PS10 with integral Vitosolic 100, type SD1 rU
or
Solar-Divicon, type PS20 without control unit with separate Vitosolic, type SD1
rU
Z012 018
Z012 027
rE
Solar circuit pump R1 Standard delivery pos. 42
rR
Collector temperature sensor KOL Standard delivery pos. 47
rT
Solar collector See Viessmann pricelist
rU
Vitosolic 100, type SD1 Z007 387
rO
Expansion vessel, solar circuit See Vitoset pricelist
Natural cooling function (NC)
iP
NC-Box with mixer Z009 565
iQ
3-way diverter valve Standard delivery pos. 80
iW
Secondary cooling circuit pump Standard delivery pos. 80
iE
Contact humidistat Standard delivery pos. 80
iR
Primary cooling circuit pump Standard delivery pos. 80
iT
Mixing valve Standard delivery pos. 80
iI
2-way valve Standard delivery pos. 80
iO
Flow temperature sensor VTS 7183 288
Heating/cooling circuit without mixer A1
oP
Underfloor heating circuit/cooling circuit A1 See Vitoset pricelist
oQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
– Wireless base station
– Vitotrol 200 RF wireless remote control
– Wireless outside temperature sensor
– Wireless repeater
Z011 413
Z011 219
7455 213
7456 538
oW
Overflow valve on site
oE
Temperature limiter to restrict the maximum temperature of underfloor heating systems (option-
al)
7151 728 or 7151 729
qCP
Connection module with single room control, heating/cooling with pump logic 7247 845
qCQ
Room thermostat (installation on finished walls), heating/cooling RTR-E 6726 7247 853
qCW
Thermal actuator TS 5.11/230 (N/C, cores can be interchanged)
or
Thermal actuator TS+ 5.11/230 (N/C, cores can be interchanged)
7373 722
7419 860
Accessories (optional)
8
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
oI
LON communication module 7172 173
qXP
Vitocom 100 type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100 type LAN 1 with communication module Z011 224
qXW
Vitocom 200 type LAN 2 with communication module Z011 390
qXE
Vitocom 200 type GP 3 with communication module with SIM card Z011 392
Vitocal 200-G
(cont.)
64
VIESMANN
System examples
3
5822 472 GB
