Viessmann Vitocal 200-A - Equipment required; Heat source; Primary circuit; DHW heating

Equipment required
ID: 4605087_1304_05
Pos. Designation Part no.
Heat source
1
2
Compact heat pump Vitocal 222/242/333/343-G with:
– Integral control unit
– Primary pump
– Secondary pump
– 3-way diverter valve for "Central heating/DHW heating"
– Cylinder loading pump (only 242/343-G)
– DHW cylinder
– Cylinder temperature sensor
See Viessmann pricelist
3
Outside temperature sensor ATS Standard delivery pos. 1
4
Instantaneous heating water heater Standard delivery pos. 1
qW
Safety assembly Standard delivery pos. 1
qE
Expansion vessel, heating circuit See Vitoset pricelist
Primary circuit
wP
Brine accessory pack ZK00 300
wQ
Pressure switch, primary circuit 9532 663
wW
Brine distributor for geothermal probes/geothermal collectors See Viessmann pricelist
wU
Geothermal probe/geothermal collector on site
DHW heating
eU
Connection set with DHW circulation pump ZP 7440 932
DHW heating with a solar thermal system
rQ
High limit safety cut-out STB 7506 168
rW Solar-Divicon, type PS10 with integral solar control module, type SM1 rU
or
Solar-Divicon, type PS20 without control unit with separate solar control module, type SM1
rU
Z012 016
Z012 027
rE
Solar circuit pump Standard delivery pos. 42
rR
Collector temperature sensor KOL Standard delivery pos. 47
rT
Solar collector See Viessmann pricelist
rZ
Junction box on site
rU
Solar control module, type SM1 7429 073
rI
Cylinder temperature sensor SOL Standard delivery pos. 47
rO
Expansion vessel, solar circuit See Viessmann pricelist
Heating circuit without mixer A1
oP
Underfloor heating circuit See Vitoset pricelist
oW
Overflow valve on site
oR
Temperature limiter to restrict the maximum temperature of underfloor heating systems
– Version with immersion sensor
or
7151 728
– Version with contact sensor 7151 729
Accessories (optional)
8
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
zU
Radio clock receiver 7450 563
oQ
Vitotrol 200A remote control Z008 341
oT
Vitotrol 300B remote control Z011 411
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
– Wireless base station
– Vitotrol 200 RF wireless remote control
– Wireless outside temperature sensor
– Wireless repeater
Z011 413
Z011 219
7455 213
7456 538
oI
LON communication module 7172 173
qXP
Vitocom 100, type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100, type LAN 1 with communication module Z011 224
qXW
Vitocom 200, type LAN 2 with communication module Z011 390
qXE
Vitocom 200, type GP 3 with communication module with SIM card Z011 392
Vitocal 222-G/242-G/333-G/333-G NC/343-G
(cont.)
12
