Equipment required
ID: 4605351_1304_03
Pos. Designation Part no.
1
Heat pump See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
4
Instantaneous heating water heater See Viessmann pricelist
5
Primary pump (integrated for type BWC) See Viessmann pricelist
6
Secondary pump (integrated for type BWC) See Viessmann pricelist
7
Circulation pump for cylinder heating UPSB (integrated for type BWC) See Viessmann pricelist
8
Safety equipment block with safety assembly (integrated for type BWC) 7143 779
9
Expansion vessel secondary circuit See Vitoset pricelist
qP
Outside temperature sensor ATS Standard delivery pos. 4
qW
Geothermal probe/geothermal collector on site
qE
Brine distributor for geothermal probes/geothermal collectors See Viessmann pricelist
qR
Brine accessory pack See Viessmann pricelist
qT
Pressure switch, brine circuit 9532 663
DHW heating
wP
DHW cylinder See Viessmann pricelist
wQ
Cylinder temperature sensor STS 7170 965
wW
DHW circulation pump ZP on site
Heating water buffer cylinder
eP
Heating water buffer cylinder See Viessmann pricelist
eQ
Buffer temperature sensor PTS 7170 965
eW
Flow temperature sensor system VTS 7170 965
Active cooling function (AC)
qZ
AC-Box (active cooling) 7245 606
rP
Separate cooling circuit on site
rQ
Room temperature sensor separate cooling circuit RTS 7408 012
rW
Flow temperature sensor separate cooling circuit VTS 7183 288
rE
Fan convector See Viessmann pricelist
rR
Condensate drain on site
rT
Circulation pump, UP AC on site
rZ
Contactor relay K1 7814 681
Heating circuit with mixer M2
tP
Underfloor heating circuit See Vitoset pricelist
tE
Flow temperature sensor VTS M2 7183 288
tR
Temperature limiter to restrict the maximum temperature of underfloor heating systems 7151 728 or 7151 729
tT
Heating circuit pump UP M2 on site
tZ
Mixer motor M2 7450 657
Heating circuit without mixer A1
zP
Radiator heating circuit See Vitoset pricelist
zE
Heating circuit pump UP A1 on site
Accessories (optional)
qQ
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
tQ/
zQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
-Wireless base station Z011 413
-Vitotrol 200 RF wireless remote control Z011 219
-Wireless repeater 7456 538
oI
LON communication module 7172 173
qXP
Vitocom 100, type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100, type LAN 1 with communication module Z011 224
qXW
Vitocom 200, type LAN 2 with communication module Z011 390
qXE
Vitocom 200, type GP 3 with communication module with SIM card Z011 392
qXR
Vitocom 300, type LAN 3 with LON communication module Z011 399
qXT
Vitocom 300, type GP 4 with LON communication module Z011 400
Vitocal 300-G/350-G
(cont.)
