Equipment required
ID: 4605507_1304_02
Pos. Designation Part no.
1
Heat pump Vitocal 200-A See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1C Standard delivery pos. 1
3
Outside temperature sensor ATS Standard delivery pos. 1
4
Instantaneous heating water heater with switching module Standard delivery pos. 1
5
3-way diverter valve for "Central heating/DHW heating" Standard delivery pos. 1
6
Secondary pump SUP Standard delivery pos. 1
7
Flow temperature sensor VTS Standard delivery pos. 1
qW
Safety equipment block with safety assembly Standard delivery pos. 1
qE
Expansion vessel See Vitoset pricelist
qR
High limit safety cut-out STB 70 °C (for switching off the secondary pump) on site
qT
Flow switch SW Standard delivery pos. 1
DHW heating (cylinder loading system)
eP
DHW cylinder See Viessmann pricelist
eQ
Cylinder temperature sensor STS 7438 702
eE
Cylinder loading pump SLP 7820 403
eR
Plate heat exchanger See Viessmann pricelist
eT
Flow limiter on site
eZ
2-way motorised valve 7180 573
eU
DHW circulation pump ZP See Viessmann pricelist
eI
Heating lance See Viessmann pricelist
External heat source
tP
External heat source (oil/gas boiler) with Vitotronic 200, type KO1B, KO2B or KW6B See Viessmann pricelist
tQ
External EA1 extension for oil/gas boiler 7452 091
tW
Circulation pump for cylinder reheating See Viessmann pricelist
tE
Boiler water temperature sensor KTS (for connection to the heat pump)
– As contact temperature sensor
or
7438 463
– As immersion temperature sensor 7438 702
tR
Mixer motor directly controlled 7441 998
tT
High limit safety cut-out STB 70 °C (for switching off the external heat source) on site
tZ
Contactor relay K1 7814 681
tU
Contactor relay K2 7814 681
Heating water buffer cylinder
zP
Heating water buffer cylinder See Viessmann pricelist
zQ
Buffer temperature sensor PTS 7438 702
zW
Flow temperature sensor system VTS Standard delivery pos. 54
Heating/cooling circuit with mixer M2 (KM BUS)
uP
Underfloor heating circuit/cooling circuit See Vitoset pricelist
uQ
Vitotrol 200A remote control
or
Z008 341
oW
Vitotrol 300B remote control Z011 411
The following wireless accessories are available as an alternative to hardwired remote con-
trol units:
oO
– Wireless base station
– Vitotrol 200 RF wireless remote control
– Wireless outside temperature sensor
– Wireless repeater
Z011 413
Z011 219
7455 215
7456 538
q-T
Extension kit with mixer, comprising: 7301 063
uE
Flow temperature sensor VTS and mixer motor Standard delivery pos. 105
uR
Temperature limiter to restrict the maximum temperature of underfloor heating systems
– As immersion thermostat
or
7151 728
– As contact thermostat 7151 729
uZ
Heating circuit pump on site
uU
3-way mixer See Viessmann pricelist
qCP
Connection module with single room control, heating/cooling with pump logic 7247 845
qCQ
Room thermostat (installation on finished walls), heating/cooling RTR-E 6726 7247 853
qCW
Thermal actuator TS 5.11/230 (N/C, cores can be interchanged)
or
Thermal actuator TS+ 5.11/230 (N/C, cores can be interchanged)
7373 722
7419 860
Active cooling function AC
qI
Frost stat FSW 7179 164
iE
Contact humidistat 230 V~ FAS 7452 646
iI
3-way diverter valve for "Heating/cooling" 7814 924
iO
3-way diverter valve for "Heating/cooling" 7814 924
Vitocal 200-A
(cont.)
System examples
VIESMANN
197
5822 472 GB
6
