Viessmann VITOCAL 300-A - Equipment required

Equipment required
ID: 4605092_1304_05
Pos. Designation Part no.
1
Heat pump Vitocal 300-A See Viessmann pricelist
2
Heat pump control unit Vitotronic 200, type WO1B Standard delivery pos. 1
with electrical connecting cables See Viessmann pricelist
3
Outside temperature sensor ATS Standard delivery pos. 2
4
Instantaneous heating water heater, 3, 6, or 9 kW For AWCI: Z006 463
For AWO: Z007 884
5
– For type AWCI: 3-way diverter valve for "Central heating/DHW heating"
or
For AWCI: Standard delivery
– For type AWO: Circulation pump for cylinder heating UPSB See Viessmann pricelist
6
Secondary pump For AWCI: Standard delivery
For AWO: see the Viessmann pricel-
ist
7
Flow temperature sensor VTS (integral for type AWCI) Standard delivery pos. 1
qW
Safety equipment block with safety assembly For AWCI: Standard delivery
For AWO: 7143 779
qE
Expansion vessel See Vitoset pricelist
qT
Flow switch Standard delivery pos. 1
DHW heating
eP
DHW cylinder Vitocell 100-V, type CVW 390 litres Z002 885
eQ
Cylinder temperature sensor STS 7170 965
eU
DHW circulation pump ZP See Vitoset pricelist
Heating/cooling circuit without mixer A1
oP
Underfloor heating circuit/cooling circuit See Vitoset pricelist
oQ
Vitotrol 200A remote control Z008 341
The following wireless accessories are available as an alternative to hardwired remote control
units:
oO
-Wireless base station Z011 413
-Vitotrol 200 RF wireless remote control Z011 219
-Wireless repeater 7456 538
oW
Overflow valve on site
oR
Temperature limiter to restrict the maximum temperature of underfloor heating systems
– As immersion thermostat
or
7151 728
– As contact thermostat 7151 729
qCP
Connection module with single room control, heating/cooling with pump logic 7247 845
qCQ
Room thermostat (installation on finished walls), heating/cooling RTR-E 6726 7247 853
qCW
Thermal actuator TS 5.11/230 (N/C, cores can be interchanged)
or
Thermal actuator TS+ 5.11/230 (N/C, cores can be interchanged)
7373 722
7419 860
Active cooling function (AC) via heating/cooling circuit
qI
Frost stat 7179 164
iE
Contact humidistat 230 V 7452 646
oE
Flow temperature sensor cooling circuit VTS 7183 288
Accessories (optional)
8
KM BUS distributor (if there is more than one KM BUS subscriber) 7415 028
oI
LON communication module 7172 173
qXP
Vitocom 100, type GSM 2 Z011 396 / Z011 388
qXQ
Vitocom 100, type LAN 1 with communication module Z011 224
qXW
Vitocom 200, type LAN 2 with communication module Z011 390
qXE
Vitocom 200, type GP 3 with communication module with SIM card Z011 392
qXR
Vitocom 300, type LAN 3 with LON communication module Z011 399
qXT
Vitocom 300, type GP 4 with LON communication module Z011 400
Vitocal 300-A/350-A
(cont.)
206
VIESMANN
System examples
7
5822 472 GB
