Vitocell 100-E/100-W, type SVW (200 l capacity)
Steel heating water buffer cylinder for storing heating
water in combination with heat pumps and solid fuel
boilers, with optional electric heater (immersion
heater).
Suitable for systems to EN 12828 and DIN 4753.
Vitocell 100-E: In Vitosilver
Vitocell 100-W: In white
Vitocell 100-E, type SVP/SVPA (400, 750 and 950 l capacity)
Heating water buffer cylinder for storing heating water
in combination with heat pumps, solar thermal sys-
tems, solid fuel boilers and heat recovery.
Suitable for systems to EN 12828 and DIN 4753.
Connections
Type SVW (200 l capacity)
Fig. 1 Front
A
Thermometer sensor retainer
B
Thermometer (TH)
C
Female connection for immersion heater (EHE)
Installation information
Product information
5517 175 GB
Installation
