Graphics Series
• ARAG
®
screen treatment
This specially formated anti-reflection, anti-
glare screen treatment uses a multi-layer
process to refract light away from the user
while maintaining the highest quality image.
• OnView controls including ViewMatch
All screen adjustments are made via an on-
screen menu using simple controls. The
ViewMatch feature allows the user to adjust
color temperature and individual color
intensity for screen-to-print matching.
• TCO'99 and Energy 2000 certified
This monitor complies with the world’s strictest
standards of low radiation, safety,
ergonomics, recycling and power
management while saving costs
through automatic power saving
modes.
• PC and Mac
®*
compatible
• Three-year limited warranty
24/7 free technical and customer service.
*Free universal Mac adapter available. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the
property of their respective companies. Copyright © 2001 ViewSonic Corporation. All rights reserved. [10320-00B-09/01_5M] VS-2118
17" (16.0" VIEWABLE) PERFECTFLAT
®
COLOR MONITOR
CRT Type 17" (16.0" viewable) CRT, 90º deflection
Dot Pitch 0.21mm horizontal, 0.13mm vertical, 0.25mm diagonal
Phosphor RGB medium/short persistence
Glass Surface Tint (TM~38%), ARAG
®
screen treatment
SIGNAL
Video RGB Analog (75 ohms, 0.7 Vp-p)
Sync H/V Separated (TTL), Composite
Frequency f
h
:30~86kHz; f
v
:50~180Hz
COMPATIBILITY
PC IBM and PC compatible from VGA up to 1600 x 1200
Mac
®*
Power Mac™ from 640 x 480 up to 1280 x 1024
CONNECTOR
Signal 15-pin mini D-sub (attached)
Power 3-pin plug (IEC320)
POWER
Voltage AC 90-132V/198-264VAC (auto switch), 50/60 (+/– 3) Hz
Consumption 80W (typ)
CONTROLS
Basic Power, On/Off, 1, Down, Up, 2
OnView
®
Contrast, brightness, H/V position, H/V size, pincushion,
zoom, trapezoid, pinbalance, parallelogram, tilt,
top hook, bottom hook, degauss, H/V moiré reduction,
input level, language, ViewMatch
®
Color (9300, 6500,
5000, User), ViewMeter
®
, OSD position, recall
VIDEO INPUT Bandwidth 135MHz (typ)
MISCONVERGENCE 0.25mm (max at center), 0.35mm (max at corner)
DISPLAY AREA
Factory Setting 310mm (H) x 232mm (V)
Maximum Scan 325mm (H) x 244mm (V) (dependent upon signal timing used)
OPERATING
Temperature 32-104º F (0-40º C)
CONDITION Humidity 5-95% (non-condensation)
DIMENSIONS
Physical 408mm (W) x 420mm (D) x 428mm (H)
(16.1" x 16.5" x 16.8")
WEIGHT Net 16.2kgs (35.7 lbs)
REGULATIONS UL,
CUL, DHHS, FCC-B, ICES-003,TCO’99, ENERGY STAR
®
,
Energy 2000, CB, VCCI, C-TICK, BSMI, NOM, TUV/GS,
TUV-ERGO
POWER MANAGEMENT Meets E
NERGY STAR
®
, TCO‘99 and
Energy 2000 standards
WARRANTY Three-year limited warranty on CRT, parts and labor.
Express Exchange
®
service option available.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
381 Brea Canyon Road, Walnut, CA 91789 • Phone (800) 888-8583 or (909) 444-8888 • Fax (909) 839-7922 • E-mail: SalesInfo@ViewSonic.com • ViewSonic.com
