- 21 –
ViewSonic Corporation
Confidential - Do Not Cop VA1703w/VA1703wb
7 OVPT Over-voltage/ over-current protection threshold setting pin
8 NC No connection
9 NC No connection
10 ENA ON/OFF control of IC
11 LCT
Timing capacitor to set internal PWM dimming frequency and also a
pin for analog dimming selection
12 SSECMP Capacitor for soft start time and loop compensation
13 CT Timing resistor and capacitor for operation and striking frequency
14 GNDA Ground for analog signals
15 DRV2 Drive output
16 PGND Ground for power paths
