9
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 12.
Main Menu
with OSD controls
Front Control Panel
shown below in detail
Scrolls through menu options and adjusts
the displayed control.
Brightness (T) / Contrast (S)
(For VA1912-LED/VA1912a-LED only)
Audio Adjust (T) / Brightness/Contrast (S)
(For VA1912m-LED/VA1912ma-LED only)
Displays the control screen for
the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to toggle
analog and digital connection.
(For VA1912-LED/
VA1912m-LED only)
Also a shortcut to Auto Image
Adjust.
(For VA1912a-LED/
VA1912ma-LED only)
Power light
Blue = ON
Orange =
Power Saving
Displays the Main
Menu or exits the
control screen and
saves adjustments.
Standby Power On/Off
To Next Page
