ViewSonic Model Number: VS10866
Rev: 1b
Serial No. Prefix: Q90
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 E-00005747 MJ0A10AK01 19" Wide Semi Product,A190A2,1440X900,TN 1
2 N/A 36X8636401 Driver IC,Scan,HX8636APD400(TSMC),300Channel,,RoHS,Green I 3
3 N/A L3J009XXXX 19" wide PS TN Asahi 0.7mm glass Cr BM(Panel Base) 1
4 N/A 74-D002212
Polarizer,TFT,Degree 135,414 mmx259.7 mmx0.215 mm,NWF-LESEG,M190A1,Green
I
1
5 N/A 74-D002213
Polarizer,CF,Degree 135,415.84 mmx262.15 mmx0.215 mm,NWF-
LESEGAGS1,M190A1,Green I
1
6 N/A 73-C000047 ACF,COG,AC-8405Z-23 1.5mmX100M,100000 mmx1.5 mm,COG-ACF,Green I 0.00168
7 N/A 7344191017 ACF,AC-4251FY-16,100M/RL,Green I 0.0044
8 N/A 36-D002378
Driver IC,COF,Data,M190A1-L01,HX8018-A050CBAK,Reel,6
bit,432Channel,RoHS,Green I
10
9 N/A 73-D002676 ACF,PCB,AC-9825R-35,100000 mmx1.5 mm,PCB-ACF,Green I 0.0044
10 N/A 35-D004361 PCBA for ,A190A2-H,A190A2-A02-H-X,1206-01,Rev.01,Green I 1
11 N/A 7349951002 Silicone,TORAY/-9187L,330g 0.4
12 HW-00000533 42A9930008 SCREW,M3,P=0.5 mm,L=4 mm,Pan Head,Phillips Cross Recess,Green I 16
13 HW-00006041 42A9940007 SCREW,M4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket,Green I 2
14 N/A 41-D000643 Metal Frame Front,M190A1-L01/A190A2/M190A1-L03,SECC 0.6t,19"wide 1
15 HW-00004042 42-D000649
SCREW,M4,P=0.7 mm,L=8 mm,Round Head,Phillips Cross Recess,plate color
Zn,Screw_with_Washer,head D8,Green I
1
16 N/A 73-D002886
Conductive Tape,PET+Adhesive,409 mmx58.55 mmx0.05
mm,Mylar_Cover_PcbaX_a190a2,Green I
1
17 B-00006039 27-D003247
Lips With Audio,DAC-12M030 A,Ver:0F,5 V/3 A,12 V/0.7 A,I TYPE,7 mA,1710
V,RoHS
1
18 N/A 44-D003584 Backlight Unit,A190A2,Green I 1
19 C-00005686 41-D003772 Cover AD Assy,A190A2,SECC,without Dvi-D Hole,Green II 1
20 B-00005599 35-D005694 PCBA for ,A190A2-A02-T,A190A2-A02-H-S1,1206-04,Rev.04,ODM,Green II 1
21 CB-00005742 32-D005773 FFC,FFCX816,36 Pins,package AL_Foil,Green II 2
22 CB-00000544 32F2818004 Audio Cable,A150X2,18AWG,180cm,Black,JCE,Green I 1
23 CB-00004287 32F3018003 Accessory Cable,D-Sub,BLACK,A150X2,Green I 1
24 A-00002058 32E1818013
Power Cord,CCC,300/500V,0.75mm2,3C,PC-323+COC-01,L=1830+/-
50mm,Black,Linetek,18AWG,No Bag,Green I
1
25 HW-00000590 42A9930013 SCREW,M4,P=0.7 mm,L=15 mm,Pan Head,Green I 4
26 HW-00000555 42A9930014 Screw,M3*P0.5*6,Green I 4
27 HW-00000556 42A9990005 Screw,M3*P1.27*12,φ5.5*2,Steel,Green I 2
28 C-00004284 40-D004250 Cover Hinge,A190A2-H05,ABS PA757N,Black(J91A11B5) 1
29 C-00004282 40-D004257 Rear Assy,A190A2-H05,ABS PA757N,Black(J91A11B5) 1
30 C-00004281 40-D004255 Bezel Assy,A190A2-H05,ABS PA757N,Silver(Pantone877C) 1
31 CB-00004288 32-D004533 FFC,A190A2-H05,15 Pins,L=108.5 1
32 B-00005600 35-D005166 PCBA for ,A190A2-H,A190A2-H-K3,106-02,Rev.02,ODM,Green II 1
33 C-00004283 40-D004252 Stand Assy,A190A2-H05,ABS PA757N,Black(J91A11B5) 1
34 PL-00006048 73-D005900 Panel Protector Film,A190A2-H05,XG-536 T=0.1,With_Print,Green II 1
35 DC-00005602 77-D008324 Safety Label for ,A190A2-H05,120 mmx50 mm,VSC_VA1912w-2,Green II 1
36 N/A 77-D008330 SN Label for ,A190A2-H05,50 mmx25 mm,VSC_VA1912w-2 for China,Green II 1
37 HW-00002076 7841595111 Corner Protector,paper,50 mmx50 mmx1850 mm,Green I 1
38 N/A 7841595191
Separator,紙板(AA),1120*820*11mm,A150X2-T01,Non Green
0.025
39 P-00000595 7841919921 Bag,570 mmx600 mmx0.13 mm,White,Non Green 1
40 DC-00000586 7741999141 Label,Pallet Barcode Label,75x40,A190E2-H03,VSC,Non Green 0.021
41 M-00000560 7345511002 Tape,Security Tape,OPP,L900xW50x0.045mm,VSC,Non Green
0.3
42 N/A 77-D000114 Customer Label,A170E1-H0G,180 mm,100 mm,Green I 1
43 N/A 77-D000118 Customer Label,A170E1-H0G,130 mm,80 mm,Green I 1
44 N/A 78-D000275 Warranty Card,A170E1-H0G,143 mmx210 mm,VSC_VA712,Green I 1
45 DC-00005603 77-D000576 Carton Label for ,A190E2-H06,20 mmx20 mm,VSC_VA912_for Europe,Green I 1
46 N/A 77-D001323
Customer Label for ,A170E1-H0G,15 mmx15 mm,QC Pass Label_VSC_for
China,Green I
1
47 N/A 78-D001492 Pallet,A150X2-T01,Wooden,1150 mmx840 mmx138 mm,Green I 0.02
48 C-00004285 40-D004259 Seat Assy,A190A2-H05,ABS PA757N,Black(J91A11B5) 1
49 P-00004295 78-D004392
Cushion,A190A2-T05,EPS,WHITE,450 mmx160 mmx145 mm,PS FOAM (Left),Green
II
1
50 P-00004296 78-D004388
Cushion,A190A2-T05,EPS,WHITE,450 mmx160 mmx145 mm,PS FOAM (Right),Green
II
1
51 N/A 79-D004425 Shipping Package Information for ,A190A2-H05,ViewSonic 1
52 DC-00005604 77-D008326 Carton Label for ,A190A2-H05,76.2 mmx76.2 mm,VSC_VA1912w-2,Green II 1
53 P-00005607 78-D008325 Carton,A190A2-H05,538 mmx158 mmx470 mm,VSC_VA1912w-2,Green II 1
54 DC-00005605 76-D008375 MENU for A190E2-H05,Complex,1C,VSC_VA1912w-2,CD-ROM,Green II 1
BOM LIST (VA1912W-2)
47
Confidential - Do Not Copy VA1912w-2_VA1912wb-2
ViewSonic Corporation
