ViewSonic Model Number: VS10866
Rev: 1a
Serial No. Prefix: QBM
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 E-00005747 MJ0A10AK01 19" Wide Semi Product, A190A2, 1440X900, TN 1
2 N/A 36X8636401
Driver IC, Scan, HX8636APD400(TSMC), 300Channel, ,
RoHS, Green I
3
3 N/A L3J009XXXX 19" wide PS TN Asahi 0.7mm glass Cr BM(Panel Base) 1
4 N/A 74-D002212
Polarizer, TFT, Degree 135, 414 mmx259.7 mmx0.215
mm, NWF-LESEG, M190A1, Green I
1
5 N/A 74-D002213
Polarizer, CF, Degree 135, 415.84 mmx262.15
mmx0.215 mm, NWF-LESEGAGS1, M190A1, Green I
1
6 N/A 73-C000047
ACF, COG, AC-8405Z-23 1.5mmX100M, 100000
mmx1.5 mm, COG-ACF, Green I
0.00168
7 N/A 7344191017 ACF, AC-4251FY-16, 100M/RL, Green I 0.0044
8 N/A 36-D002378
Driver IC, COF, Data, M190A1-L01, HX8018-
A050CBAK, Reel, 6 bit, 432Channel, RoHS, Green I
10
9 N/A 73-D002676
ACF, PCB, AC-9825R-35, 100000 mmx1.5 mm, Hitachi
Chemical(日立化成), PCB-ACF, Green I
0.0044
10 N/A 35-D004361
PCBA for , A190A2-H, A190A2-A02-H-X, 1206-01,
Rev.01, Green I
1
11 N/A 7349951002 Silicone, TORAY/-9187L, 330g 0.4
12 N/A PJ0AFT0Q04
Olympic, 19"W, Function BOM, D-sub+Audio, Morning
Star, TSUM17AK
1
13 HW-00000553 42A9930008
SCREW, M3, P=0.5 mm, L=4 mm, Pan Head, Phillips
Cross Recess, Green I
16
14 HW-00006041 42A9940007
SCREW, M4, P=0 mm, L=11.8 mm, Hexagon Stand Off,
Socket, Green I
2
15 N/A 41-D000643
Metal Frame Front, M190A1-L01/A190A2/M190A1-
L03, SECC 0.6t, 19"wide
1
16 HW-00004042 42-D000649
SCREW, M4, P=0.7 mm, L=8 mm, Round Head, Phillips
Cross Recess, plate color Zn, Screw_with_Washer, head
D8, Green I
1
17 N/A 73-D002886
Conductive Tape, PET+Adhesive, 409 mmx58.55
mmx0.05 mm, Mylar_Cover_PcbaX_a190a2, Green I
1
18 B-00006039 27-D003247
Lips With Audio, DAC-12M030 A, Ver:0F, 5 V/3 A, 12
V/0.7 A, I TYPE, 7 mA, 1710 V, RoHS
1
19 N/A 44-D003584 Backlight Unit, A190A2, Green I 1
20 C-00005686 41-D003772
Cover AD Assy, A190A2, SECC, without Dvi-D Hole,
Green II
1
21 B-00006727 35-D008185
PCBA for , A190A2-A02-T, A190A2-A02-T-S1, 1208-
05, Rev.04, Green II
1
22 CB-00005742 32-D005773 FFC, FFCX816, 36 Pins, package AL_Foil, Green II 2
23 N/A
PJ0EACS000
Olympic, 19", Accessory BOM, D-sub+Audio, China 3
pin, Black, Power built-in;RoHS
1
24 CB-00000544 32F2818004
Audio Cable, A150X2, 18AWG, 180cm, Black, JCE,
Green I
1
25 CB-00004287 32F3018003 Accessory Cable, D-Sub, BLACK, A150X2, Green I 1
26 A-00002058 32E1818013
Power Cord, CCC, 300/500V, 0.75mm2, 3C, PC-
323+COC-01, L=1830+/-50mm, Black, Linetek,
18AWG, No Bag, Green I
1
27 N/A PJ0AI15100
Olympic, 19"W, ID BOM, D-sub+Audio, China, Black,
VSC, VA1912wb-2
1
28 HW-00000590 42A9930013 SCREW, M4, P=0.7 mm, L=15 mm, Pan Head, Green I 4
29 HW-00000555 42A9930014 Screw, M3*P0.5*6, Green I
4
30 HW-00000556 42A9990005 Screw, M3*P1.27*12, φ5.5*2, Steel, Green I 2
31 C-00004279 40-D004258 Cover Hinge, A190A2-H05, ABS PA757N, Green I 1
32 C-00004277 40-D004253 Rear Assy, A190A2-H05, ABS PA757N, Green I 1
33 C-00004276 40-D004254 Bezel Assy, A190A2-H05, ABS PA757N, Green I 1
34 CB-00004288 32-D004533 FFC, A190A2-H05, 15 Pins, L=108.5 1
35 B-00005600 35-D005166
PCBA for , A190A2-H, A190A2-H-K3, 106-02, Rev.02,
ODM, Green II
1
36 C-00004278 40-D004251 Stand Assy, A190A2-H05, ABS PA757N, Green I 1
37 PL-00006048 73-D005900
Panel Protector Film, A190A2-H05, XG-536 T=0.1,
With_Print, Green II
1
38 DC-00008016 77-D012194
Safety Label for , A190A2-H05, 120 mmx50 mm,
VA1912wb Ver.3, Green II
1
39 DC-00008021 77-D011737
SN Label for , A190A2-H05, 50 mmx25 mm,
_VA1912wb-2 for Analog for China, Green II
1
40 HW-00002076 7841595111
Corner Protector, paper, 50 mmx50 mmx1850 mm, Green
I
1
41 N/A 7841595191
Separator, 紙板(AA), 1120*820*11mm, A150X2-T01,
Non Green
0.025
42 P-00000595 7841919921 Bag, 570 mmx600 mmx0.13 mm, White, Non Green 1
BOM LIST (VA1912WB-2)
48
Confidential - Do Not Copy VA1912w-2_VA1912wb-2
