ViewSonic VA2248m - Wall Mounting (Optional)

ViewSonic VA2248-LED/VA2248m-LED 7
Wall Mounting (Optional) For use only with UL Listed Wall Mount Bracket
To obtain a wall-mounting kit or height adjustment base, contact ViewSonic
®
or your local
dealer. Refer to the instructions that come with the base mounting kit. To convert your LCD
display from a desk-mounted to a wall-mounted display, do the following:
Step 1. Verify that the power button is turned Off, then disconnect the power cord.
Step 2. Lay the LCD display face down on a towel or blanket.
Step 3. Remove the base and the plastic cover from the back of the stand.
Step 4. Remove the three screws attaching the stand.
Step 5. Attach the mounting bracket from the VESA compatible wall mounting kit (100 mm
x 100 mm distance), using screws of correct length.
Step 6. Attach the LCD display to the wall, following the instructions in the wall-mounting
kit.
Step 5. Four
VESA screw
holes
Step 4. Three screws
attaching the stand
Step 3. Plastic cover
