3rd Panel Source HSD 150MX17 A02
Type TN, LVDS
Active Size 304.1 mm (H) x 228.1mm (V)
Pixel Arrangement RGB Vertical Stripe
Pixel Pitch 0.297 mm
Glass Treatment Anti Glare (Hard coating 3H)
# of Backlights 2 CCFL edge-light
Backlight Life 30,000 Hours (Min)
Luminance –Condition: CT = 6500 K
Contrast = Max, Brightness = Max
250 cd/m2 (Typ after 30 minute warm up)
200 cd/m2 (Min after 30 minute warm up)
Brightness Uniformity 75 % (min)
Contrast Ratio 500 :1 (Typ), 400 :1 (Min)
Color Depth Vertical) 16.2 million colors (6+2 bit panel)
Viewing Angle (Horizontal)
120° (Typ)@ CR>10 / X° (Typ)@ CR>5
Viewing Angle (Vertical)
100° (Typ) @ CR>10 / X° (Typ)@ CR>5
Response Time
10%-90% @ Ta=25°C
12 ms (Tr= 8.5 ms, Tf = 3.5 ms) (Typ)
18 ms (Tr= 5 ms, Tf = 11 ms) (max)
Panel Defects Please see Panel Quality Specifications.
4th Panel Source SVA 150XG04TB
Type TN, LVDS
Active Size 304.1 mm (H) x 228.1mm (V)
Pixel Arrangement RGB Vertical Stripe
Pixel Pitch 0.297 mm
Glass Treatment Anti Glare (Hard coating 3H)
# of Backlights 2 CCFL edge-light
Backlight Life 30,000 Hours (Min)
Luminance –Condition: CT = 6500 K
Contrast = Max, Brightness = Max
250 cd/m2 (Typ after 30 minute warm up)
200 cd/m2 (Min after 30 minute warm up)
Brightness Uniformity 75 % (min)
Contrast Ratio 450 :1 (Typ), 350 :1 (Min)
Color Depth Vertical) 16.2 million colors (6+2 bit panel)
Viewing Angle (Horizontal)
120° (Typ)@ CR>10 / X° (Typ)@ CR>5
Viewing Angle (Vertical)
100° (Typ) @ CR>10 / X° (Typ)@ CR>5
Response Time
10%-90% @ Ta=25°C
16 ms (Tr= 4 ms, Tf = 12 ms) (Typ)
25 ms (Tr= 7 ms, Tf = 18 ms) (max)
Panel Defects Please see Panel Quality Specifications.
