INTRODUCTION
FEATURES VA503b / VA503m
Size 15 “
Luminance (Typ)
250 cd/㎡
Contrast Ratio (Typ) 500:1
Colors 16.2 M colors (6+2bit panel)
Response Time (Typ) 12 ms
Viewing Angle (H/V) 120 ° / 100 °
1
st
TFT LCD panel
Recommend resolution 1024 x 768 @60Hz
Size 15 “
Luminance (Typ)
200 cd/㎡
Contrast Ratio (Typ) 500 :1
Colors 16.2 M colors (6+2bit panel)
Response Time (Typ) 12 ms
Viewing Angle (H/V) 140 ° / 120 °
2
nd
TFT LCD panel
Recommend resolution 1024 x 768 @60Hz
Size 15 “
Luminance (Typ)
250 cd/㎡
Contrast Ratio (Typ) 500:1
Colors 16.2 M colors (6+2bit panel)
Response Time (Typ) 12 ms
Viewing Angle (H/V) 120 ° / 100 °
3
rd
TFT LCD panel
Recommend resolution 1024 x 768 @60Hz
Size 15 “
Luminance (Typ)
250 cd/㎡
Contrast Ratio (Typ) 450:1
Colors 16.2 M colors (6+2bit panel)
Response Time (Typ) 16 ms
Viewing Angle (H/V) 120 ° / 100 °
4
th
TFT LCD panel
Recommend resolution 1024 x 768 @60Hz
Analog (75ohms, 0.7/1.0 Vp-p) Yes
Input Signal
Digital (DVI-D) No
Separate Sync Yes
Composite Sync No
Sync Compatibility
Sync on Green No
PC Yes
Power Mac Yes
Compatibility
TV Box (NextVision 6) Yes
Power Voltage AC 100-240V, 50/60Hz Yes
On Mode(Max / Typ) Under 23 W in max
Power Consumption
Active Off Mode (Max) Saving mode< 2W / Off mode <1 W
Tilt ( -5 ° - 22.5 °)
Yes
Swivel No
Pivot No
Ergonomics
Height Adjust No
OSD Control [ 1 ] [ 2 ] [ ][▼] [▲] Yes
Physical (W x H x D) 344 x 347.5 x 147 (mm)
13.15 x 13.68 x 5.79 (in)
Dimension
Package (W x H x D) 396 x 400 x 141 (mm)
15.59 x 15.75 x 5.55 (in
Physical (Net Weight) 2.7 kg / 5.95 lbs
Weight
Package (Gross Weight) 3.7 kg / 8.16 lbs
Temperature (℉/℃) 32℉~104℉ / 0℃~40℃
Operating Condition
Humidity (%) 20 % - 90 %
Temperature (℉/℃) -4℉~140℉ / -20℃~60℃
Storage Condition
Humidity (%) 5 % - 90 %
Regulation
CB / TCO99 / UL/cUL / FCC-B / ICES 003 / Argentina-TUV/S / NOM / EPA Energy Star /
TUV/Ergo / ISO134062 / TUV/GS / CE / GOST-R / SASO / BSMI / PSB / C-Tick / CCC / RoHS
/ WEEE
ViewSonic Corporation VA503b-1_ VA503m-1
