Installation of Wall Mount (Optional)
To obtain a wall-mounting kit, contact ViewSonic or your local dealer. Refer to
the instructions that come with the base mounting kit. To convert your
LCD display from a desk-mounted to a wall-mounted display, do the following:
1
Disconnect Power.
2
Push the LCD display back and
down flat against the base as
shown.
3
Lay the LCD display face down on
a towel or blanket. Notice the
four screw holes on the bottom of
the base.
4
Attach the mounting bracket
from the VESA compatible wall-
mounting kit (75 mm x 75 mm
distance).
5
Attach the LCD display to the wall,
following the instructions in the
wall-mounting kit.
Four
screw
holes
Mounted
on the wall
ViewSonic VE155b 5
