ViewSonic VG2228WM-LED User Manual

14
Control Explanation
Fine Tune sharpens the focus by aligning text and/or graphics with pixel
boundaries.
NOTE: Try Auto Image Adjust first.
Sharpness adjusts the clarity and focus of the screen image.
Dynamic Contrast allows the user to turn the contrast ratio enhancement on or
off.
Aspect ratio Selects the image size for 4:3 and full screen.
ECO Mode provides the lower power consumption by reducing the brightness.
Standard: The default brightness setting.
Optimize: Decreases the brightness by 25 %.
Conserve: Decreases the brightness by 50 %.
Setup Menu displays the menu shown below:
Language Select allows the user to choose the language used in the menus and
control screens.
Resolution Notice advises the optimal resolution to use.
OSD Position allows the user to move the OSD menus and control screens.
OSD Timeout sets the length of time the OSD screen is displayed. For example,
with a “15 second” setting, if a control is not pushed within 15 seconds, the
display screen disappears.
OSD Background allows the user to turn the OSD background On or Off.
Auto Power Off, if enabled, will power off the display automatically when no
signal is detected for 3 minutes.
Power Indicator allows the user to select the Power Indicator On/Off for
Power On/Off mode.

ViewSonic VG2228WM-LED Specifications

General

3D	No
Display diagonal	22 \
Vertical scan range	50 - 75 Hz
Horizontal scan range	24 - 82 kHz
Viewable size diagonal	546.1 mm
Viewable size, vertical	269.24 mm
Viewing angle, vertical	160 °
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewable size, horizontal	477.52 mm
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
Ethernet LAN (RJ-45) ports	0
USB hub version	2.0
USB Type-A downstream ports quantity	2
Certification	CB, TCO'05, WEEE, UL/cUL, FCC-B, IRAM, NOM, EPEAT Silver ERGO, CE, Ukraine, GOST-R+Hygienic, SASO, BSMI, PSB, C-TICK, KCC, CCC
Product color	Black
Market positioning	Business
Compliance industry standards	RoHS
RMS rated power	4 W
Panel mounting interface	- mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	21 W
Package depth	160 mm
Package width	582 mm
Package height	500 mm
Cables included	USB
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	412.02 mm
Weight (with stand)	4400 g
Depth (without stand)	61.7 mm
Width (without stand)	510.9 mm
Height (without stand)	305.9 mm
Weight (without stand)	3500 g
