ViewSonic VX2245wm 8
Wall Mounting (Optional)
To obtain a wall-mounting kit, contact ViewSonic
®
or your local dealer. Refer to the
instructions that come with the base mounting kit. To convert your LCD display from a desk-
mounted to a wall-mounted display, do the following:
1. Verify that the Power button is turned Off, then
disconnect the power cord.
2. Lay the LCD display face down on a towel or
blanket.
3. Remove the Plastic Covers from the back of the
LCD display.
4. Remove the four screws attaching the base.
5. Remove the Rubber Plugs from inside the four
VESA screw holes.
6. Attach the mounting bracket from the VESA
compatible wall mounting kit (100 mm x 100 mm
distance).
7. Attach the LCD display to the wall, following the
instructions in the wall-mounting kit.
Four VESA screw holes
