11
Removing the Stand and Mounng the Monitor
Refer to the table below for the standard dimensions for mounng kits.
NOTE:  For use only with a UL cered mounng kit/bracket. To obtain a wall
mounng kit or height adjustment base, contact ViewSonic® or your
local dealer.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw
Specicaon
Screw
Quanty
14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm M4 x 10 mm 4 pieces
NOTE:  Mounting kits are sold separately.
1. Turn o the monitor and disconnect all cables.
2. Place the monitor on a at, stable surface with the screen facing down.
3. Remove the stand.
4. Aach the mounng bracket to the VESA mounng holes at the rear of the
monitor. Then secure it with four screws (M4 x 10 mm).
100 mm
100 mm
5. Follow the instrucons that come with the mounng kit to mount the monitor.
