ELECTRIC OUTLET LOCATION
WATER LINE ENTRY AREA
6
-
3
/
4
”
(
1
7
.
1
c
m
)
7
-
5
/
8
”
(
1
9
.
4
c
m
)
3
”
(
7
.
6
c
m
)
5
/
8
”
(
1
.
5
c
m
)
5
/
8
”
(
1
.
5
c
m
)
1
0
-
1
/
2
”
(
2
6
.
7
c
m
)
5
/
8
”
(
1
.
5
c
m
)
1
0
-
3
/
4
”
(
2
7
.
3
c
m)
1
”
(
2
.
5
c
m
)
3
-
5
/
8
”
(
9
.
2
c
m
)
O
p
t
i
on
a
l
f
l
o
o
r
w
a
t
e
r
l
i
n
e
e
n
t
r
y
9
”
(
2
2
.
9
c
m
)
REFRIGERATION
Quiet Cool™ Built-In 48”W. Side-By-Side
Refrigerator/Freezer
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
R E V I S E D 7 / 1 2 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
UTILITY
REQUIREMENTS
GAS
Not applicable
ELECTRICAL
• Three-wire cord
with grounded
three-prong plug
attached to
product
• 115 VAC/60 Hz;
15 amp dedicat-
ed circuit
• Maximum amp
usage—9.9
• Estimated
energy usage—
668 kWh/year
PLUMBING
• Inlet waterline
requirements—
1/4”copper
tubing
• 20 psi min.;
120 psi max.
Installation Requirements
ACCESS REQUIREMENTS
VCSB548 VISB548/DDSB548 DFSB548
Cutout width 47-1/2” (120.7 cm) min. to 48” (121.9 cm) 48” (121.9 cm)
47-3/4” (121.3 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.*
*Custom panel models fit flush in 25”-deep (63.5 cm)
cabinet openings. They can be installed in standard
24”-deep openings. The door faces and top grille
will protrude 3/4” (1.9 cm) into the room.
See Custom Panels section for
more information and additional
specifications.
VCSB548/VISB548
Professional/Professional
Integrated
DFSB548
Custom Panel
DDSB548
Designer
