PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
RELEASED 12/1/07
©2007 VRC—INFORMATION SUBJECT TO CHANGE
KITCHEN CLEANUP
Undercounter 18”W. Trash Compactor
Please see
Installation Notes &
Accessories
for important
information,
including handle
kits, bags/ties,
and filters.
VUC181
Professional
DUC180
Designer
DFC180
Custom Front
23-5/8”
(60.0 cm)
2-7/8”
(7.3 cm)
34-3/16”
(86.8 cm) min.
to
35-11/16”
(90.6 cm) max.
3-1/2”
(8.9 cm)
17-13/16”
(45.2 cm)
23-7/8”
(60.6 cm)
2-7/8”
(7.3 cm)
34-1/8”
(86.7 cm) min.
to
35-1/2”
(90.2 cm) max.
3-1/2”
(8.9 cm)
17-13/16”
(45.2 cm)
VUC181 DUC180 DFC180
Overall width 17-13/16” (45.2 cm)
Overall height 34-3/16” (86.8 cm) min. to 34-1/8” (86.7 cm) min. to 34-1/8” (86.7 cm) min. to
35-11/16” (90.6 cm) max. 35-1/2” (90.2 cm) max. 35-1/2” (90.2 cm) max.
Overall depth
To edge of side
(includes door panel) 23-5/8” (60.0 cm) 23-7/8” (60.6 cm) 23-7/8” (60.6 cm)
With door open 48-1/8” (122.2 cm) 45-3/4” (109.8 cm) 45-3/4” (109.8 cm)
Dimensions & Specifications
PRODUCT DIMENSIONS
PROFESSIONAL DESIGNER
See Custom Panels section for
more information and additional
specifications.
