TECHNICAL DATA
MODEL VXD SINGLE-
INTERLOCKED PREACTION
SYSTEM WITH ELECTRIC
RELEASE
The Viking Corporation, 210 N Industrial Park Drive, Hastings MI 49058
Telephone: 269-945-9501 Technical Services: 877-384-5464 Fax: 269-818-1680 Email: techsvcs@vikingcorp.com
Visit the Viking website for the latest edition of this technical data page www.vikinggroupinc.com
Page 13 of 13
Form No. F_051820 21.01.01 Rev 21.1
Figure 10: Dimensions - 8"
Figure 11: Dimensions - 10"
All dimensions are approximate.
All dimensions are approximate.
Not to scale.
Not to scale.
48" 48"
16"
14"
12"
13"
