EN
Programming phase:
1. Lift the handset and place to the ear.
2. Press and hold down the stair light push button “
”.
3. After 2 seconds the interphone emits a high tone.
4. Release the stair light push button
“ ” and press again to
restore to the default value.
Deleting all programmed settings.
This procedure is recommended when you want to change the
ID of a previously programmed entryphone/video entryphone
and you do not need to retain the programmed operation
settings of the device.
Programming phase:
1. Lift the handset and place to the ear.
2. Press and hold down the door lock push button “
” for 6 s.
3. When the time runs out the internal unit will emit a “beep” in the
handset (0.5 s).
4. Continue to hold down the door lock push button
5. After 2 s more the internal unit emits two “beeps” set apart
(duration 0.5 s with a space in between).
6. Continue to hold down the door lock push button “
”.
7. After 2 s more the internal unit emits a continuous tone for 5 s
8. Release the door lock push button “
”.
9. While the internal unit is still emitting a continuous tone, press
the door lock push button “
”.
10. When the door lock push button “
” is released three “beeps”
will be emitted.
Operation
Calls from an entrance panel, intercom calls and door calls are
identied by dierent tones.
The call ringtone is on the handset; if the handset is o the hook,
the call rings at a lower volume which can only be heard when the
handset is at the ear.
Entrance panel call
Calls from entrance panels do not correspond to the presses of
the call button but are generated internally in the entryphone.
The call interval is 1 second of ringtone and 2 seconds of pause
repeated twice (default value set on panel). To answer, raise the
handset. If the handset is already raised when the call is received,
replace it and then lift it again. The call answer time (30 s) and
the conversation time (2 minutes by default) are set in the panel
parameters When the conversation time has elapsed, the user can
continue without replacing the handset if a new call is made within
10 seconds from the same panel.
Intercom call
Lift the entryphone handset and press the intercom button. On the
handset of the entryphone called, you will hear a call tone (if the
call is enabled) or an engaged tone (if not enabled). On the called
entryphone, the ringtone will start with a cycle of 1 second ringing
followed by a 4 second pause. The maximum duration of the call is
30 seconds (6 cycles). To answer the call, simply raise the handset;
the maximum duration of the conversation is 5 minutes. When
the conversation time has elapsed, the user can continue without
replacing the handset if a new call is made within 10 seconds. A
call from an entrance panel will take priority over an intercom call.
Lock release button
On every device, the door lock button “ ” functions as described
below.
- Device with handset in rest position door lock function
directed to the entrance panel it was last in communication with
or from which the call was made.
- Device with handset raised, but no conversation in progress
call to switchboard if the switchboard ag is set to YES. Otherwise
the rst case applies.
- Device with handset raised and intercom conversation in progress
as in the rst case.
- Device with handset raised and intercom conversation in progress
door lock function directed to the entrance panel with which
the device is in communication or from which the call was made.
In practice, the button always operates the lock release except when
you raise the handset and immediately press the lock button. This
too can be set as the standard case if there is no switchboard in the
system and the switchboard ag is set to NO.
In SaveProg there is also a Door Lock to Master ag, used to force
the entryphone when the hook is down or in the rest position, to
send the door lock command only to the Master panel, however
the push button is programmed and whatever the entrance panel
it was last in communication with or from which the call was made.
9
8879.1 - 8879.1/D
