30
EN
SIMPLE AUDIO DOOR ENTRY SYSTEM
WITH SPEECH UNIT ART. 6931 AUDIO DOOR
ENTRY UNITS ART. 6209 AND ART. 8879.
(REF. SI431).
A0 - INTERPHONE Art. 6901, Art. 6901/D
A1 - INTERPHONE SERIE PETRARCA Art. 6209
A2 - INTERPHONE SERIE 6600
Art. 6601/AU, 660C/AU, 6701/AU
Art. 6611/AU, 661C/AU, 6711/AU, Art. 6xxx/AUF
A3 - INTERPHONE SERIE 8870 Art. 8879
A6 - INTERPHONE SERIE TAB Art. 7509
C3 - AUDIO ENTRANCE PANEL 8000, 1200, 8100,
1300, 3300, 2550/301-302, patavium SERIES
C3.0- AUDIO SPEECH UNIT ART. 6931
C3.7- POWER SUPPLY LED
C3.8- SUPPLEMENTARY MODULE
Art. 8051, 8052, 8053, 8054, 12TS
F - POWER SUPPLY type 6922
K- PUSHBUTTON FOR CALL FROM OUTSIDE THE DOOR
L- ELECTRIC LOCK 12~
P- DOOR CONTROL
X - CABLE type 732H, type 732I (Two twisted wires)
NOTE:
When the speech unit Art. 6931 has more than 4 supple-
mentary modules Art. 8054, remove the jumper C3.7 and
connect a supplementary power supply to the terminals
(VL)+ and (M)-.
5
2
2
1
4
1
6S
6P
B
A
C
A
C
B
4
5
6S
2
1
6P
1
E+
FP
E-
2
M
CH
+12
B
A
C
4
T2
5
6S
T1
2
1
A
T4
-
+
C
B
VIDEO
T3
6P
1
2
2
2
1
1
12V
CH
B
A
C
FP
M
PRI
B2B12
1
C3
C3.0
B2
S+
S-
B1
M
CA
CBA
C3.9
C3.7
M
VL
C3.8
C3.2
C3.1
C3.4
C3.3
C3.5
C3.6
CN10
X
L
K
A0
A2
A3
A1
F
Rete-Mains-Reseau
Netz-Red- Rede
K
K
K
K
X
X
X
X
X
X
P
A6
