31
EN
VIDEO INTERPHONE ENTRANCE PANEL
SYSTEM FOR SINGLE OR MULTI RESI-
DENCE WITH MONITORS TYPE PETRARCA,
GIOTTO, 6600 AND A VIDEO ENTRANCE
PANEL (REF. SI527).
NOTE:
When the speech unit Art. 6931 has more than
4 supplementary modules Art. 8054 (8051, 8052,
8053, 8054) und 12TS, remove the jumper C3.7
and connect a supplementary power supply to the
terminals (VL)+ and (M)-.
PRI
B2B12
1
1
2
6P
T3
VIDEO
B
C
+
-
T4
A
1
2
T1
6S
5
T2
4
1
2
1
E+
FP
E-
2
M
CH
+12
M
V3
A
C
B
4
12
2
3
1
13
B
A
C
B2
S+
S-
B1
M
CA
C3.5
-
1
2
+
CBA
C3.9
C3.7
M
VL
C
B
A
C3.9
C3.8
C3
C3.2
C3.1
C3.4
C3.3
C3.5
C3.6
C3.0
ART. 6931
C
A
B
+12
CH
M
2
E-
FP
E+
1
+I+U-
PRI
Mains
Wire supplied
with type 6570 - 657C
CN10
X
X
X
X
X
X
L
X
P
K
K
K
K
B3
B1
B2
B2
B0
B5
B4
F- Art. 6922
G- Art. 6923
B0- MONITOR SERIES WIDE TOUCH
ART. 7211
B1 - MONITOR SERIES 7200 ART. 7211
B2 - MONITOR SERIES 6600
Art. 6621, 662C, 6721
Art. 6611, 661C, 6711,
Art. 6xxx/F
B3 - MONITOR SERIES 6800
Art. 6801, Art. 68MV + 68M1
B4 - MONITOR SERIES PETRARCA
Art. 6029/C + 6209 + 6145
Art. 6029 + 6209 + 6145
B5 - MONITOR SERIES GIOTTO
Art. 6329, 6329/C
C3 - AUDIO ENTRANCE PANEL 8000 SERIES,
LETTER BOX 2501 - 2502
C3.0- AUDIO SPEECH UNIT ART. 6931
C3.5- CAMERA
C3.7- POWER SUPPLY LED
C3.8- SUPPLEMENTARY MODULE
Art. 8051, 8052, 8053, 8054, 12TS
F - POWER SUPPLY type 6922
G - POWER SUPPLY type 6923
K- PUSHBUTTON FOR CALL FROM OUTSIDE THE
DOOR
L- ELECTRIC LOCK 12~
P- DOOR CONTROL
X - CABLE type 732H, type 732I (Two twisted wires)
Mains
