Power supply
Art. 6582
Mains
SIMPLE VIDEO ENTRANCE PANEL SYSTEM WITH SPEECH UNIT TYPE 6931 AND SEPARATE
CAMERA BY MEANS OF INTERFACE TYPE 693T (REF. SI559).
Tab. 2 (Art. 693T)
Termi-
nals:-, +U
Max. distance: 100m
Max. load: 250mA with Art. 6582
Section of conductors: 1 mm² up to 50m
1.5 mm² up to 100m
Tab. 1 (Art. 693T)
Terminals:
-, 12
Max. distance: 100m
Section of conductors: 1 mm² up to 100m
Terminals:
M, V
Distanza Max: 100m
con Cavo coassiale 75 Ohm tipo RG59
Terminals:
C3.5
Max. distance: 100m
Section of conductors: 1 mm² up to 100m
Note: Use the cable supplied with type 693T
connecting by means of terminal blocks two
conductors to reach the required distance.
C3 - AUDIO ENTRANCE PANEL 8000, 1200,
1300, 8100, 3300, 2550/301-302,
PATAVIUM SERIES
C3.0- AUDIO SPEECH UNIT ART. 6931
C3.7- POWER SUPPLY LED
C3.8- SUPPLEMENTARY MODULE
Art. 8051, 8052, 8053, 8054, 12TS
F - POWER SUPPLY type 6922
K- PUSHBUTTON FOR CALL FROM OUTSIDE
THE DOOR
L- ELECTRIC LOCK 12~
P- DOOR CONTROL
X - CABLE type 732H, type 732I (Two twisted wires)
1
2
3
Interfaccia
Art. 693T
CN10
1
2
3
P
X
L
F- Art. 6922
Mains
To Next Page
