Vimar ELVOX Pixel Up Series User Manual

Caution: The camera must be equipped with its own power supply unit with suitable characteristics. Check that the type of power supply unit
and the connections do not cause any interference with the operation of the electronic unit. Otherwise an insulation lter such as art. 692G
can be used.
D - Audio-video entrance panel with display and keyboard 40425
F - System power supply unit 6922.1
F3- Power supply unit for external CCTV camera
P - Electric lock
L - Additional lock control button
X - Twisted cable 732H.E, 732I.E
ConnectionvariantforAudiopanel41425withexternalCCTVcamera
We recommend you insert a 100 Ohm termination at the video input of the entrance panel if the camera does not play back any video.
10
EN
PIXEL UP: 40404 - 40424
PRI
B22
1
B1
21
B2
B1
CA+
CA-
S-
S+
E-
E+
41005UP
41019UP
41018UP
41030UP
NC
C
NO
CA-
CA+
NC
C
NO
OUT2 OUT1
V
M
PRI
F
6922.1
P
L
X
D
F3
Video entryphone/entryphone riser
Mains
Mains
