Vimar ELVOX SW24.W User Manual

20
SW24.W
OUT
A2
Gate left open (OAB)
On if the gate remains open for a
time longer than that dened by
the open gate alarm logic (L16)
5
Maintenance (MAN)
Output o󰀨 when the number of
maintenance signalling manoeu-
vres (MNPS) is reached in the
diagnostics section
6
Synchronization output, com-
pass type interlock (INB)
Automatically congures input S4
as synchronization input without
any choice by the user.
The control panel consents to the
gate opening only if the other gate
is in the closed position.
7
Synchronization output, com-
pass type interlock (INP) with
presence signal.
Automatically congures input S4
as synchronization input and S3 as
presence input without any choice
by the user. The control panel con-
sents to the gate opening only if the
other gate is in the closed position
and the presence input is occupied.
8
RAU
Auxiliary Radio Output Congu-
ration
(1)
Impulsive: the output is active for
1 s following the RAU command
from the remote control
1
Timed: the output is active for the
time set in the RAUT parameter
following the RAU command from
the remote control
2
Bistable: the output works in Step-
Step ON/OFF mode
3
RAUT
RAU output timing (1)
1 s (minimum time) 1
600 s (maximum time) 600
LCO
Courtesy light timer (120)
1 s (minimum time) 1
300 s (maximum time) 300
OUT
SCA
SCA output operating mode (1)
Gate closed: o󰀨
Gate open: on xed
1
Gate closed: o󰀨
Gate moving: intermittent
Gate open: on xed
Indeterminate position: intermittent
pause of 1 s every 5
2
Gate closed: o󰀨
Gate opening slow intermittent
Gate open on xed
Gate closing intermittent
Indeterminate position: intermittent
pause of 1s every 5
3
Gate stopped on xed
Gate moving o󰀨
4
Gate closed o󰀨
Gate moving on xed
5
IN
Input conguration
Sub
menu
Description Values
(default)
C(X)
C1/C2/C3/C4 command input
Step-step (PP)
The step-step control:
- with the gate stopped and
closed, opens the gate
- in opening, stops or closes the
gate according to the step-step
logic setting (L10)
- with the gate stopped after open-
ing, closes the gate
- in closing, stops or opens the
gate according to the step-step
logic setting (L10)-with the gate
stopped after closing, opens the
gate
1
(C1)
Pedestrian (PED)
Opens the gate to the pedestrian
position
It acts like a step-step if the com-
mand is given with the gate in a
position beyond the pedestrian
position
2
(C2)
Open (OPEN)
The open command:
- with the gate stopped and
closed, opens the gate
- in opening is ignored
- with the gate open, resets the
pause time
- with the gate stopped, opens the
gate
- in closing, opens the gate
3
(C3)
EN
