19
SW24.W
TRV
T36
Acceleration time when opening
motor 1
(0.5)
Maximum acceleration (0 s to
reach normal speed)
0
Minimum acceleration (2.0 s to
reach normal speed)
2.0
T37
Acceleration time when opening
motor 2
(0.5)
Maximum acceleration (0 s to
reach normal speed)
0
Minimum acceleration (2.0 s to
reach normal speed)
2.0
T38
Acceleration time when closing
motor 1
(0.5)
Maximum acceleration (0 s to
reach normal speed)
0
Minimum acceleration (2.0 s to
reach normal speed)
2.0
T39
Acceleration time when closing
motor 2
(0.5)
Maximum acceleration (0 s to
reach normal speed)
0
Minimum acceleration (2.0 s to
reach normal speed)
2.0
Note:
T36, T37, T38, T39 are the times during which the
motor accelerates to reach the normal opening
speed (adjustable at intervals of 0.1 s)
T40
Deceleration ramp motor 1 (30)
Steep ramp (maximum decelera-
tion)
0
Low ramp (minimum deceleration) 100
T41
Deceleration ramp motor 2 (30)
Steep ramp (maximum decelera-
tion)
0
Low ramp (minimum deceleration) 100
Note:
T40 and T41 are the deceleration ramp between
normal motor speed and slowdown speed.
OUT
Auxiliary output conguration
Sub
menu
Description Values
(default)
19
Electric lock (1)
Output o󰀨 OFF
Electrical solenoid lock 1
Electrical drop lock 2
Electrical magnetic lock (suction)
on in closing
3
Electrical magnetic lock (suction)
on in opening and closing
4
19T
Electrical solenoid lock excita-
tion time
(adjustable at intervals of 0.1 s)
(1.2)
0.5 s (minimum time) 0.5
5.0 s (maximum time) 5.0
A1
Terminal A1 output type (1)
Output o󰀨 OFF
Gate open warning light (SCA)
Operation as per SCA parameter
setting
1
Auxiliary Radio output (RAU)
Operation as per RAU parameter
setting
2
Courtesy light (LCO)
On during leaf movement and for
the amount of time after the leaf
stopping set in parameter LCO
3
Zone light (LZO)
On during leaf movement
4
Gate left open (OAB)
On if the gate remains open for a
time longer than that dened by
the open gate alarm logic (L16)
5
Maintenance (MAN)
Output o󰀨 when the number of
maintenance signalling manoeu-
vres (MNPS) is reached in the
diagnostics section
6
A2
Terminal A2 output type (2)
Output o󰀨 OFF
Gate open warning light (SCA)
Operation as per SCA parameter
setting
1
Auxiliary Radio output (RAU)
Operation as per RAU parameter
setting
2
Courtesy light (LCO)
On during leaf movement and for
the amount of time after the leaf
stopping set in parameter LCO
3
Zone light (LZO)
On during leaf movement
4
