18
SW24.W
TRV
T11
Obstacle detection time motor 2
Time after which the current
threshold or the encoder threshold
trigger the obstacle detection for
motor 2 (adjustable at intervals of
100 ms)
(20)
100 ms (minimum time) 10
600 ms (maximum time) 60
T12
Polling time
Time during which the motor
pushes with maximum force to
move the leaf (adjustable at inter-
vals of 0.5 s)
(2.0)
0.5 s (minimum time) 0.5
5.0 s (maximum time) 5.0
T13
Pedestrian opening position
(% of total opening travel of rst
leaf)
(30)
Minimum space 10
Maximum space 100
T14
Disengagement space on obsta-
cle (inversion distance following
the detection of an obstacle)
(5)
Not disengaged, stops only OFF
Minimum inversion 1
Maximum inversion 10
T15
Stop approach force reduction
distance motor 1
(OFF)
Force reduction o󰀨 OFF
Minimum force reduction distance 10
Maximum force reduction distance 100
T16
Stop approach force reduction
distance motor 2
(OFF)
Force reduction o󰀨 OFF
Minimum force reduction distance 10
Maximum force reduction distance 100
Note:
T15 and T16 indicate the distance from the me-
chanical stop starting from which the motor force is
reduced by half (used to adjust the impact of the leaf
on the mechanical stop).
This happens only when the control panel works
with encoder and proximity limit switch or without
limit switch.
T17
Easy release
Disengagement time after
manoeuvre to reduce the motor
pressure on the mechanical stop
(adjustable at intervals of 100 ms)
Caution:
Leave this parameter in OFF
when there is an electrical lock.
(OFF)
No disengagement OFF
100 ms (minimum disengaging) 10
500 ms (maximum disengaging) 50
TRV
T18
O󰀨set time in opening (3)
No o󰀨set 0
60 s 60
T19
O󰀨set time in closing (6)
No o󰀨set 0
60 s 60
T24
Normal speed when opening
motor 1
(90)
minimum speed 1
maximum speed 100
T25
Normal speed when opening
motor 2
(90)
minimum speed 1
maximum speed 100
T26
Normal speed when closing
motor 1
(90)
minimum speed 1
maximum speed 100
T27
Normal speed when closing
motor 2
(90)
minimum speed 1
maximum speed 100
T28
Slowdown speed when opening
motor 1
(30)
minimum speed 1
maximum speed 100
T29
Slowdown speed when opening
motor 2
(30)
minimum speed 1
maximum speed 100
T30
Slowdown speed when closing
motor 1
(30)
minimum speed 1
maximum speed 100
T31
Slowdown speed when closing
motor 2
(30)
minimum speed 1
maximum speed 100
T32
Slowdown distance when open-
ing motor 1
(20)
No slowdown 0
Slowdown for the whole distance 100
T33
Slowdown distance when open-
ing motor 2
(20)
No slowdown 0
Slowdown for the whole distance 100
T34
Slowdown distance when clos-
ing motor 1
(20)
No slowdown 0
Slowdown for the whole distance 100
T35
Slowdown distance when clos-
ing motor 2
(20)
No slowdown 0
Slowdown for the whole distance 100
Note:
T32, T33, T34, T35 represent the % of travel or total
work time done at slowdown speed
EN
