7) CORRECT USE OF THE STAIRLIFT IN INDEPEN-
DENT BAR AND RETRACTABLE BAR VERSIONS
WARNING: BEFORE USING THE STAIRLIFT,
READ THIS MANUAL CAREFULLY. The stairlift must
only be used in accordance with the intended uses
described in section 5.
7.1) Starting position
The stairlift is parked at one end of the staircase with
the platform folded up (Fig. 8/a) and the bars in rest
position (Fig. 8/b) with the master key turned to ON.
The stairlift is powered up.
7.2) Using the stairlift
WARNING: Always keep access to the plat-
form and the master switch unrestricted.
NEVER overload the stairlift.
1) For stairlifts with manual platform (standard).
- Bring the down side bar into the working position by
pressing the button (Fig. 9/d) on the control board at
the oor.
- Lower the platform by hand.
- If the stairlift is at the lower oor, bring the down side
bar into the rest position to allow the wheelchair to
move onto the platform.
1) For stairlifts with motor-operated platform (optional)
- Insert the key and turn it to position (1) ON using the control
board at the oor.
- Open the platform by pressing the button provided (Fig. 9/e).
The side guard moves to the drive-on position and the down
side bar to the working position.
If the stairlift is at the lower oor, return the down side bar
to the rest position to allow the wheelchair to move onto the
platform.
2) Get onto the platform, facing in the travel direction
and in a central position (Fig. 10) to allow the guard
to move into its sensor position. Lock the wheelchair
brakes. If the wheelchair is electric, turn it off.
WARNING: The wheelchair must be positio-
ned on the platform so that no part of the body or
the wheelchair projects from the platform. When
the stairlift is in motion sit still without moving or
rocking.
3) Insert the key (Fig. 9/m) and turn it to position (1) ON, then
turn to S and release.
4) Press the up button (Fig. 9/i); the guards and bars
automatically move to the safety position and the stai-
rlift sets off.
In stairlifts with an intermediate stop, press the button
(Fig. 9/l) once to select the rst stop, press twice for
the second stop, three times for the third stop, and so
on. Then keep the up/down button pressed until the
landing oor is reached.
The yellow light of the button (Fig. 9/l) ashes upon
selection and until arrival to the selected oor, then the
light is on without ashing.
In case the oor selection is wrong, keep the button
pressed for 3 seconds to reset, then select again
RH CONTROL
BOARD ON LIFT
LH CONTROL
BOARD ON LIFT
FLOOR
CONTROLS
