vimec V74 B.R. User Manual

32
Dis. 7801106.1PEDANA
RIF CODICE QTA' DESCRIZIONE DESCRIPTION BESCHREIBUNG DESCRIPCION DESCRIPTION
1 2804310 1 TELAIO 830x700 V64 FRAME 830x700 V64 CHASSIS 830x700 V64 CHASIS 830x700 V64 BATI-DORMANT 830x700 V64 1 2804309 1 TELAIO 830x650 V64 FRAME 830x650 V64 CHASSIS 830x650 V64 CHASIS 830x650 V64 BATI-DORMANT 830x650 V64 1 2804311 1 TELAIO 830x770 V64 FRAME 830x770 V64 CHASSIS 830x770 V64 CHASIS 830x770 V64 BATI-DORMANT 830x770 V64 1 2804313 1 TELAIO 1050x770 V74 FRAME 1050x770 V74 CHASSIS 1050x770 V74 CHASIS 1050x770 V74 BATI-DORMANT 1050x770 V74 1 2804312 1 TELAIO 1050x700 V74 FRAME 1050x700 V74 CHASSIS 1050x700 V74 CHASIS 1050x700 V74 BATI-DORMANT 1050x700 V74 2 2594390 1 PROTEZIONE SX L=700 LEFT PROTECTION L=700 AUFKLAPPE LINKS L=700 PROTECCION IZQ. L=700 PROTECTION SX L=700 2 2594394 1 PROTEZIONE SX L=650 LEFT PROTECTION L=650 AUFKLAPPE LINKS L=650 PROTECCION IZQ. L=650 PROTECTION SX L=650 2 2594392 1 PROTEZIONE SX L=770 LEFT PROTECTION L=770 AUFKLAPPE LINKS L=770 PROTECCION IZQ. L=770 PROTECTION SX L=770 3 2594391 1 PROTEZIONE DX L=700 RIGHT PROTECTION L=700 AUFKLAPPE RECHT L=700 PROTECCION DER. L=700 PROTECTION DX L=700 3 2594395 1 PROTEZIONE DX L=650 RIGHT PROTECTION L=650 AUFKLAPPE RECHT L=650 PROTECCION DER. L=650 PROTECTION DX L=650 3 2594393 1 PROTEZIONE DX L=770 RIGHT PROTECTION L=770 AUFKLAPPE RECHT L=770 PROTECCION DER. L=770 PROTECTION DX L=770 4 2874163 1 DOPPIO FONDO 830x700 V64
BOTTOM SAFE EDGE 830x700 V64 DOPPELTER BODEN 830x700 V64
DOUBLE FONDO 830x700 V64 DOUBLE FOND 830x700 V64
4 2874162 1 DOPPIO FONDO 830x650 V64
BOTTOM SAFE EDGE 830x650 V64 DOPPELTER BODEN 830x650 V64
DOUBLE FONDO 830x650 V64 DOUBLE FOND 830x650 V64
4 2874164 1 DOPPIO FONDO 830x770 V64
BOTTOM SAFE EDGE 830x770 V64 DOPPELTER BODEN 830x770 V64
DOUBLE FONDO 830x770 V64 DOUBLE FOND 830x770 V64
4 2874166 1 DOPPIO FONDO 1050x770 V74
BOTTOM SAFE EDGE 1050x770 V74 DOPPELTER BODEN 1050x770 V74
DOUBLE FONDO 1050x770 V74 DOUBLE FOND 1050x770 V74
4 2874165 1 DOPPIO FONDO 1050x700 V74
BOTTOM SAFE EDGE 1050x700 V74 DOPPELTER BODEN 1050x700 V74
DOUBLE FONDO 1050x700 V74 DOUBLE FOND 1050x700 V74
5 2594388 1 PROTEZIONE V74 PROTECTION V74 AUFKLAPPE V74 PROTECCION V74 PROTECTION V74 5 2594284 1 PROTEZIONE V64 PROTECTION V64 AUFKLAPPE V64 PROTECCION V64 PROTECTION V64 6 2874167 2 TAPPO CAP STOPFEN TAPON BOUCHON 7 3424306 2 ASTA ROD STANGE ASTA TIGE 8 2504069 2 CAMMA CAM ENDSCHALTSKURVE LEVA CAME 9 2904064 4 LEVA SENSORE LEVER HEBEL PALANCA LEVIER 10 1334033 4 BOCCOLA BUSH BUCHSE BOCCOLA BAGUE 11 2504039 4 SENSORE SENSOR SENSOR SENSOR SENSEUR 12 2254603 2 CAVO CABLE KABLE CABLE CABLE 13 4254272 2 ATTACCO CONNECTION ANSCHLUSSWINKEL FIJACION FIXATION 14 1304148 2 PERNO PIN ZAPFEN PERNIO GOUJON 14 1304185 2 PERNO BANDELLA L=650 PIN L=650 ZAPFEN L=650 PERNIO L=650 GOUJON L=650 15 1902024 2 MICRO MICROSWITCH MIKROSCHALTER MICRO MICROINTERRUPTEUR 16 5214099 2 PIASTRINA PLATE PLATTE PLANCHA PLATTE 17 0714040 4 MOLLA SENSORE SPRING FEDER RESORTE RESSORT 18 0714025 4 MOLLA DOPPIO FONDO SPRING FEDER RESORTE RESSORT 19 0714062 4 MOLLA BANDELLA SPRING FEDER RESORTE RESSORT 20 2804231 1 PEDANA 830x700 V64 PLATFORM 830x700 V64 PLATTFORM 830x700 V64 PLATAFORMA 830x700 V64 PLATE-FORME 830x700 V64 20 2804277 1 PEDANA 830x650 V64 PLATFORM 830x650 V64 PLATTFORM 830x650 V64 PLATAFORMA 830x650 V64 PLATE-FORME 830x650 V64 20 2804278 1 PEDANA 830x770 V64 PLATFORM 830x770 V64 PLATTFORM 830x770 V64 PLATAFORMA 830x770 V64 PLATE-FORME 830x770 V64 20 2804315 1 PEDANA 1050x770 V74 PLATFORM 1050x770 V74 PLATTFORM 1050x770 V74 PLATAFORMA 1050x770 V74 PLATE-FORME 1050x770 V74 20 2804314 1 PEDANA 1050x700 V74 PLATFORM 1050x700 V74 PLATTFORM 1050x700 V74 PLATAFORMA 1050x700 V74 PLATE-FORME 1050x700 V74
