Dis. 7801189.1BARRE DI SICUREZZA
RIF CODICE QTA' DESCRIZIONE DESCRIPTION BESCHREIBUNG DESCRIPCION DESCRIPTION
1 2894838 1 TELAIO DX RIGHT FRAME RAHMEN RECHTS CHASIS DER. CHASSIS DROIT 1 2894837 1 TELAIO SX LEFT FRAME RAHMEN LINKS CHASIS IZQ. CHASSIS GAUCHE 2 4204091 1 BRACCIO PER 830x770 V65 PROTECTION ARM 830x770 V65 SCHUTZARM 830x770 V65
BRAZO DE PROTECCION 830x770 V65
BRAS DE PROTECTION 830x770 V65
2 4204119 1 BRACCIO PER 830x650 V65 PROTECTION ARM 830x650 V65 SCHUTZARM 830x650 V65
BRAZO DE PROTECCION 830x650 V65
BRAS DE PROTECTION 830x650 V65
2 4204120 1 BRACCIO PER 830x700 V65 PROTECTION ARM 830x700 V65 SCHUTZARM 830x700 V65
BRAZO DE PROTECCION 830x700 V65
BRAS DE PROTECTION 830x700 V65
2 4204233
1
BRACCIO PER 830x600 V65 PROTECTION ARM 830x600 V65 SCHUTZARM 830x600 V65
BRAZO DE PROTECCION 830x600 V65
BRAS DE PROTECTION 830x600 V65
3 2824414 2 CARTER DI CERNIERA HINGE HOUSING SCHARNIERGEHÄUSE CARTER DE CREMALLERA CARTER DE CHARNIERE 4 2824411 2 COFANO FIANC SIDE CASE SEITLICHE HAUBE CAPÓ LATERAL CAPOT FLANC 5 2894718 1 GIUNZIONE JOINT VERBINDUNG UNION JOINT 6 0482064 1 TAPPO CAP STOPFEN TAPON BOUCHON 7 2594368 1 SUPPORTO SUPPORT TRÄGER SOPORTE SUPPORT 7 2504158 1 CAMMA E FERMO ANTIVANDALO
CAM AND VANDAL-RESISTANT LOCK
NOCKE UND. ANHALTEVORRICH. GEGEN VANDAL.
PALANCA Y TRABA ANTIVANDALISMO
CAME ET ARRET ANTIVANDALISME
8 3424294 2 PIASTRINA PLATE PLATTE PLANCHA PLAQUE 9 4404243 3 CERNIERA HINGE SCHARNIER CHARNELA CHARNIERE 10 3334017 1 BLOCCO CAMME DX RIGHT CAM BLOCK NOCKENSPERRE RECHTS BLOQUEO LEVAS DER. BLOC CAMES DROITES 10 3334016 1 BLOCCO CAMME SX LEFT CAM BLOCK NOCKENSPERRE LINKS BLOQUEO LEVAS IZQ. BLOC CAMES GAUCHES 11 1334048 1 BUSSOLA BUSHING BUCHSE BRUJULA DOUILLE 12 1334059 1 BUSSOLA GLY 28 BUSHING GLY 28 BUCHSE GLY 28 BRUJULA GLY 28 DOUILLE GLY 28 13 1334060 1 BUSSOLA GLY 20 BUSHING GLY 20 BUCHSE GLY 20 BRUJULA GLY 20 DOUILLE GLY 20 14 2564029 1 GANCIO PER CAVO HOOK HAKEN FÜR KABEL GANCHO CROCHET POUR CABLE 15 2254635 1 CAVO CABLE KABEL CABLE CABLE 16 2754009 1 FORCELLA FORK GABEL HORQUILLA FOURCHETTE 17 6102017 1 MOTORE MOTOR MOTOR MOTOR MOTEUR 18 1334052 2 BOCCOLA BUSH BUCHSE BOCCOLA BAGUE 19 3774016 1 REGISTRO REGISTER REGELUNG REGISTRO REGLAGE 20 2752007 1 FORCELLA FORK GABEL HORQUILLA FOURCHETTE 21 1302021 1 BLOCCO BLOCK SPERRE BLOQUEO BLOC 22 2254603 1 CAVO BANDELLA CABLE RAMPENKABEL CABLE BANDA CABLE 23 2304361 1 LAMIERA DI SBLOCCO RELEASE PLATE ENTSPERRBLECH CHAPA DE DESBLOQUEO TOLE DE DEBLOCAGE 24 1902027 1 MICRO LAVORO MICROSWITCH MIKROSCHALTER MICRO MICROINTERRUPTEUR 25 1902030 1 MICRO ANT.COLL. MICROSWITCH MIKROSCHALTER MICRO MICROINTERRUPTEUR 26 0904144 2 DISTANZIALE SPACING DISTANZSTÜCK SEPARADOR ENTRETOISE 27 5214099 2 PIASTRA PLATE PLATTE PLACA PLAQUE 28 1902024 1 MICRO RIPOSO MICROSWITCH MIKROSCHALTER MICRO MICROINTERRUPTEUR 29 0010009 2 DADO INGABBIATO CAGE NUT KÄFIGMUTTER TUERCA ECROU 30 0714119 2 MOLLA INCERN. FIANCHETTO SMALL SIDE HINGED SPRING SEITENSCHARNIERFEDER RESORTE CREMALLERA LATERAL
RESSORT A CHARNIERE PETIT FLANC
31 2824412 1 CARTER ANTERIORE FRONT HOUSING VORDERGEHÄUSE CARTER ANTERIOR CARTER ANTERIEUR 32 2824413 1 CARTER POSTERIORE REAR HOUSING HINTRERGEHÄUSE CARTER POSTERIOR CARTER POSTERIEUR
