Vincent
15
1. LED: Status-LED for power control
Lights, when the unit is turned on and plugged
into an appropriate outlet.
FRONT VIEW
1
2. INPUT 300W: Digital
Connect up to two digital sources (CD Player,
DVD-Player etc.) at each Schuko plug.
3. INPUT 1900W: Analogue
Connect up to four analogue sources
(Full amplifiers, preamplifiers, power amplifiers) at
each Schuko plug.
4. POWER: On/Off-Switch:
Turns the unit on and off. The device
is separated from the mains in the switched off
state.
5. AC 220-240V: Power jack
Bring the power cord here and connect
it to the power supply.
6. RESET:
By pressing this button, the device is
restarted should the device fuse interrupt.
REAR VIEW
2 3 5
4
6
