VINGLI CD0BN4D - Assembly Steps: Hutch Construction; Step 9: Assemble Hutch Boards; Step 10: Attach Hutch to Desktop

STEP 9
STEP 10
A1
A1
J
J
⑩
⑬
⑪
⑪
A×4
J×2
A1
⑫
⑫
A1×10
A2
A2
A1
A1
⑪
⑬
⑪
A1
A1
A1
A1
A1
A1
A1
A1
A1
ASSEMBLY>MANUAL support@vingli.com
ASSEMBLY STEPS
First,screws four bolts(A1) into two boards(11).Second,attach boards(11) into
board(10),insert four cams(A2) into board(10),make sure the arrows are facing
the smaller holes which the bolts go into,with a screwdriver turn the cams
about 1/2 turn clockwise to lock into place.CAUTION: Do not overtighten cams.
Then attach board(13) to board(10) using two bolts(J).
Attach hutch into desktop by aligning the bolts and cams(A).
First,screw ten bolts(A1) into desktop from STEP 8 and make sure the bolts
are tighten enough.Second,attach part from STEP 9 and boards(12) into
desktop.
