ASSEBMLY STEPS
STEP 14
21
11
15
Dx2
4x35mm
D
X2
!
15
Connect the Drawer Back Panel #11 to the Drawer Support
Panel #15 with Screw (D). Note to distinguish the front and
back of the Drawer Support Panel
