ASSEMBLY STEPS
STEP 24
31
Dx1
4x35mm
Connect the Drawer Back Panel #18 to the Drawer Support
Panel #20 with Screw (D). Note to distinguish the front and
back of the Drawer Support Panel
D
!
18
20
20
