Step 7
Insert (5) 1 1/2” x7/8”Corss Member into
the pre-routed Arbor Post to attach (2)
Arbor Post with the assembled side panel.
Repeat this step to create another Arbor
side
Step 8
Step 9
Step 11
Step 10
Slide two (2) Side Connection on the short
ends of each of the Arbor Posts. Same as
step 1 and step 2.
Repeat this step to create another Arbor
side.
Draw four markers on the ground. The
markers should be spaced apart as shown in
the diagram above.
Put the assembled side panel on the
stake with two (2) Arbor Post. It should
be10” stake into the Arbor Post
Insert the stake in the marked position. 10” above the
ground and 10” under the ground.Repeat this step to
insert the another three (3) stakes.
Step 12
Put another assembled side panel on the
stake with two (2) Arbor Post. It also
should be10” stake into the Arbor Post
10”
10”
Notch
21.9”
39.6”
D
F
G
To Next Page
