Model No.
VC28S
Type
Built-in in-column Installation (Fully Integrated)
Capacity
Total Storage Volume - L 65
Wine Storage Bottles Zone One 24
Zone Two N.A
Zone Three N.A
Performance & Features
Ambient Temp. Range °C/°F 16 ~ 33 / 60 ~90
Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72
Power Source V/Hz 115/60 220-240/50
Energy Consumption KWh/24h 0.52
Rated Input W 100 85
Rated Current A 1.0 0.6
Heater W N.A
Noise Level dB(A) 44
Defrost Type Automatic
Temp. Control Electronic
Blowing Agent Cyclopentane
Refrigerating System
Cooling System Air Forced Convection
Type
Compressor Model No. JK1111HY D53CY
Type Hermetic Type
LRA 12.5 8.1
RLA 0.80 0.55
Overload Protector 4TM232VH
BYY
B35—120
PTC Starter
QP2-4.7/B
3
QP2—15
Oil ISO8/ISO1
0 175ml
S8P 150ml
(MO)
Condenser Fan Motor Model No.
N.
A
Rating N.A
Evaporator Fan Motor Model No.
TD8020LS/YM1208PKS3
Rating
12 V DC, 0.08
A
/
0.09
A
Expansion device Capillary (Ø0.7x1200mm)
Refrigerant / Charged Volume R600a/0.57
Oz
R600a/18g
Dimensions & Weights
Net Dimensions Width – mm / in 590/23¼"
Height – mm / in 455/17⅞"
Depth – mm / in 608/24"
Packing Dimensions Width – mm / in 650/25⅝”
Height – mm / in 515/20¼"
Depth – mm / in 650/25⅝”
Weight Net / Gross – KG / Lb 29/64 / 32/71
* Specifications are subject to change without prior notice.
