2. SPECIFICATIONS
Model No.
VC7S
Type
Built-in or Free Standing Installation
Capacity
Total Storage Volume - L 20
Wine Storage Bottles Zone One 7
Zone Two N.A
Zone Three N.A
Performance & Features
Ambient Temp. Range °C/°F 16 ~ 38 / 60 ~100
Setting Temp. Range °C/°F 5 ~ 22 / 40 ~ 72
Power Source V/Hz 100/50,60 220-240/50
Energy Consumption KWh/24h 0.51
Rated Input W 60
Rated Current A 1.0 0.4
Heater W 40 N.A
Noise Level (dB(A) re 1 pW) 44
Defrost Type Automatic
Temp. Control Electronic
Blowing Agent Cyclopentane
Refrigerating System
Cooling System Air Forced Convection
Type
Compressor Model No. VY35R00A B35C
Type Hermetic Type
LRA
RLA 0.85/0.75
Overload Protector DRB21N61
A1
BR B 1 0 K 6
1 A 1 1 0 9
PTC Starter QP2-4R7 Q P 2 - 1 5
Oil Mineral Oil
(MO)
Condenser Fan Motor Model No.
TD8020LB
YM1208PKB3
Rating 12 V DC, 0.08 A/0.09A
Evaporator Fan Motor Model No.
TD8020LS
Expansion device Capillary
(Ø0.7 x 1200 mm)
Refrigerant / Charged Volume R600a/0.50
Oz
R600a/14g
Dimensions & Weights
Net Dimensions Width – mm / in 148/5⅞"
Height – mm / in 820/32¼"
Depth – mm / in 570/22½"
Packing Dimensions Width – mm / in 190/7½"
Height – mm / in 865/34¼"
Depth – mm / in 570/22½"
Weight Net / Gross – KG / Lbs 18/40 / 19/42
* Specifications are subject to change without prior notice.
