Viper 99cc - Page 21

Operator’s Manual
Viper® 99cc 4-Cycle Engine
21
For additional information email info@ardisam.com or call 800-345-6007 M-F 8-5
99CC ENGINE MAIN PARTS LIST
REF
NO.
PART
NO. DESCRIPTION QT Y.
1 10060 KIT VALVE COVER 1
2 10066 GOVERNOR ARM 1
3 10067 THROTTLE CONTROL 1
4 10078 KIT CARBURETOR REPLACEMENT 1
5 10079 VACUUM BREATHER TUBE 1
6 10095 RECOIL ASSEMBLY 1
7 10099 FLYWHEEL 1
8 10101 ENGINE CUTOFF SWITCH 1
9 10102 IGNITION COIL 1
10 13780 CAP FUEL TANK SEALED 1
11 10118 DIPSTICK WITH SEAL 1
12 10119 OIL PLUG WITH SEAL WASHER 1
13 13894 KIT MUFFLER 1
14 10146 KIT THROTTLE CONTROL SPRINGS 1
15 10147 KIT STARTER CUP AND BLOWER FAN 1
16 10148 KIT BLOWER HOUSING 1
17 13895 KIT AIR CLEANER 1
18 10150 KIT CARBURETOR TUNE UP 1
19 13925 KIT GASKETS 1
20 13896 KIT FUEL LINE 1
21 13897 KIT FUEL TANK 1
22 10236 KIT REPLACEMENT AIR FILTER ELEMENT 1
23 --- SHORT BLOCK FOR REFERENCE ONLY 1
24 13898 KIT AUXILIARY AIR INTAKE 1
25 13778 FUEL VAPOR HOSE ASSEMBLY 1
NON-SERVICED PARTS (For Reference Only)
26 --- NUT M6 X 1.0 HHFNYLK 1
27 --- BOLT M6 X 1.0 X 12 8 HD HHFCS GR8.8 ZN 4
28 --- SPARK PLUG LG E5TC 1
29 --- BOLT M6 X 20 HHFCS 8 HD GR8.8 ZN 2
30 --- NUT M6 X 1.0 HSF GR8.8 ZN 2
31 --- BOLT M6 X 1.0 X 8 HHFCS GR8.8 YL ZN 5
32 --- BOLT M6 X 1.0 X 12 HHFCS GR 8.8 ZN T/T 7
NOT SHOWN PARTS
--- 13975 KIT ALTITUDE 3000 TO 6000 FT ---
--- 13976 KIT ALTITUDE 6000 TO 8000 FT ---
