Inst.300*V iro n*EVO*Poo l*& *S pa*Pump*V0 1 _ 1 5 *
11
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
• All&model&Viron&eVo&pumps&and&compatible&VX&Timer&model&chlorinator&or&Viron&Salt&Chlorin ator
• Timer&peri ods&set&up&in&chlorinator
• Low,&medi u m&or& high&speed&can&be&selected&for&each&timer&period
• Data&cable&conn ecting&pump&to&chlorinator&via&comm s &interface&module
• eVoPump&to&be&set&up&with&timer&periods&deactivated
• Pump&speed&can&be&changed&from&pump&(from&chlorinator&early&2012)
240v power
24v data
Comms%Power%
Supply%Transfomer
•
All&model&Viron&eVo&pumps,&VX&S&(non&timer)&model&chlorinator&and&Viron&Connect&Remote&Control&System
• Timer&periods&set&up&in&controller
• 3&program mable&spee d &se ttings&on&p ump
• Se lect&low,&medium& or&high&speed&during&each&timer&period
• Data&cables&connecting&pump/chlorinator/co ntroller
• eVo&Pump&to&be&set&up&with&timer&periods&deactivated
• Pump&speed&can&be&changed&from&pump&or&controller
240v power
24v data
